Test Date: 2015-09-08 14:41
Analysis date: 2015-11-23 17:47
Analysis date: 2015-11-23 17:47
M4560 XRayHRQualification
Summary
| Module | Module | M4560 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.84/99.19 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.08 | 0.74 | 134.6 | 0 | 45.4 | 0/0 | 0 | 2026 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.26 | 1.18 | 139.5 | 0 | 47.0 | 0/0 | 0 | 1983 | 182 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.82 | 98.99 | 0.78 | 114.7 | 0 | 38.7 | 0/0 | 0 | 1995 | 171 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.30 | 0.95 | 170.4 | 0 | 57.5 | 0/0 | 0 | 2090 | 157 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.08 | 0.43 | 173.4 | 0 | 58.4 | 0/0 | 0 | 2117 | 172 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.29 | 0.60 | 184.0 | 0 | 62.1 | 0/0 | 0 | 2155 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.00 | 0.53 | 166.4 | 0 | 56.1 | 0/0 | 0 | 2133 | 168 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 99.27 | 0.60 | 167.8 | 0 | 56.6 | 0/0 | 0 | 2117 | 158 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.30 | 0.78 | 171.3 | 0 | 57.8 | 0/0 | 0 | 2125 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 99.32 | 0.57 | 186.5 | 0 | 63.0 | 0/0 | 0 | 2147 | 174 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.27 | 0.99 | 204.3 | 0 | 69.3 | 0/0 | 0 | 2191 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.24 | 0.85 | 187.5 | 0 | 63.4 | 0/0 | 0 | 2126 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.22 | 0.51 | 190.6 | 0 | 64.6 | 0/0 | 0 | 2189 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.27 | 0.68 | 129.4 | 0 | 43.8 | 0/0 | 0 | 2052 | 173 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.24 | 0.52 | 147.9 | 0 | 50.0 | 0/0 | 0 | 2079 | 160 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 98.97 | 0.86 | 148.7 | 0 | 50.2 | 0/0 | 0 | 2083 | 168 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 5 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 9 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
