Test Date: 2015-11-23 11:06
Analysis date: 2015-11-23 18:02
Analysis date: 2015-11-23 18:02
M4562 XRayHRQualification
Summary
| Module | Module | M4562 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.13 | % |
| Noise | Mean Noise | 178 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 98.93 | 0.23 | 12.3 | 41.6 | 0 | 0/0 | 0 | 1871 | 171 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 98.91 | 0.83 | 14.0 | 47.8 | 0 | 0/0 | 0 | 1894 | 185 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.27 | 0.37 | 11.9 | 40.9 | 0 | 0/0 | 0 | 1839 | 177 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.26 | 0.62 | 21.6 | 71.0 | 0 | 0/0 | 0 | 1969 | 177 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.06 | 0.60 | 23.1 | 76.2 | 0 | 0/0 | 0 | 1968 | 189 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.84 | 99.26 | 0.95 | 27.5 | 89.0 | 0 | 0/0 | 0 | 1994 | 185 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.90 | 99.35 | 0.38 | 25.9 | 84.6 | 0 | 0/0 | 0 | 1995 | 181 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.21 | 1.02 | 27.8 | 90.6 | 0 | 0/0 | 0 | 1954 | 180 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.34 | 0.70 | 29.2 | 95.8 | 0 | 0/0 | 0 | 2013 | 182 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.83 | 99.06 | 0.89 | 26.9 | 88.1 | 0 | 0/0 | 0 | 1963 | 161 | 2 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.30 | 0.66 | 30.3 | 97.5 | 0 | 0/0 | 0 | 2012 | 179 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.81 | 99.03 | 0.95 | 24.4 | 80.1 | 0 | 0/0 | 0 | 1972 | 164 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.00 | 0.83 | 23.9 | 78.2 | 0 | 0/0 | 0 | 1967 | 203 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.03 | 0.33 | 13.8 | 46.9 | 0 | 0/0 | 0 | 1870 | 171 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.12 | 0.45 | 15.2 | 51.3 | 0 | 0/0 | 0 | 1899 | 173 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 98.93 | 0.35 | 14.2 | 47.5 | 0 | 0/0 | 0 | 1905 | 166 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
