Test Date: 2015-09-04 15:40
Analysis date: 2015-11-23 18:14
Analysis date: 2015-11-23 18:14
M4570 XRayHRQualification
Summary
| Module | Module | M4570 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.80/99.10 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.84 | 98.97 | 0.68 | 135.1 | 2 | 45.6 | 0/0 | 0 | 2069 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.30 | 0.58 | 134.0 | 0 | 45.3 | 0/0 | 0 | 2062 | 162 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.20 | 0.52 | 113.7 | 0 | 38.4 | 0/0 | 0 | 2024 | 163 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.27 | 0.60 | 175.3 | 0 | 59.2 | 0/0 | 0 | 2188 | 165 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.86 | 99.24 | 0.65 | 173.5 | 1 | 58.6 | 0/0 | 0 | 2145 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.24 | 0.84 | 188.2 | 0 | 63.3 | 0/0 | 0 | 2173 | 169 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.26 | 0.76 | 169.3 | 0 | 56.8 | 0/0 | 0 | 2143 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.00 | 0.91 | 165.3 | 0 | 55.2 | 0/0 | 0 | 2148 | 163 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 98.99 | 0.87 | 175.2 | 0 | 58.9 | 0/0 | 0 | 2165 | 166 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.84 | 99.04 | 1.54 | 179.4 | 0 | 60.3 | 0/0 | 0 | 2151 | 150 | 2 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.26 | 0.63 | 198.4 | 0 | 67.2 | 0/0 | 0 | 2209 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.24 | 0.72 | 195.7 | 0 | 65.9 | 0/0 | 0 | 2225 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.25 | 0.86 | 191.1 | 0 | 64.3 | 0/0 | 0 | 2188 | 172 | 0 |
|
Chip 13
|
A
|
0 | 0 | 98.96 | 98.23 | 66.45 | 127.8 | 0 | 43.3 | 0/0 | 0 | 2102 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.92 | 0.70 | 146.5 | 0 | 49.6 | 0/0 | 0 | 2109 | 167 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.24 | 0.37 | 144.6 | 0 | 49.1 | 0/0 | 0 | 2122 | 159 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 4 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 3 | |
| channel_1_count | Channel 1 | 5 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 4 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
