Test Date: 2015-11-23 13:32
Analysis date: 2015-11-23 18:15
X-ray Calibration - Spectrum
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.4425 |
|
| medianSlope |
median Slope |
46.0355 |
|
| minSlope |
min Slope |
42.796 |
|
| maxSlope |
max Slope |
51.335 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-43.8134375 |
|
| medianOffset |
median Offset |
-41.435 |
|
| minOffset |
min Offset |
-219.83 |
|
| maxOffset |
max Offset |
110.131 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.29866666667 |
|
| medianchi2 |
median chi2 |
1.361 |
|
| minchi2 |
min chi2 |
0.003 |
|
| maxchi2 |
max chi2 |
12.567 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
45.4 e- / Vcal
|
0.2 e- / Vcal
|
25.6 e-
|
21.4 e-
|
|
1
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
-45.4 e-
|
10.3 e-
|
|
2
|
47.3 e- / Vcal
|
0.2 e- / Vcal
|
-26.2 e-
|
22.6 e-
|
|
3
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-30.5 e-
|
18.0 e-
|
|
4
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
56.9 e-
|
9.6 e-
|
|
5
|
42.8 e- / Vcal
|
0.1 e- / Vcal
|
110.1 e-
|
7.6 e-
|
|
6
|
45.9 e- / Vcal
|
0.1 e- / Vcal
|
-163.5 e-
|
18.8 e-
|
|
7
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
-110.5 e-
|
16.7 e-
|
|
8
|
46.1 e- / Vcal
|
0.1 e- / Vcal
|
-84.5 e-
|
18.6 e-
|
|
9
|
48.2 e- / Vcal
|
0.1 e- / Vcal
|
-78.0 e-
|
9.1 e-
|
|
10
|
48.6 e- / Vcal
|
0.2 e- / Vcal
|
-219.8 e-
|
18.2 e-
|
|
11
|
43.2 e- / Vcal
|
0.2 e- / Vcal
|
-110.4 e-
|
20.9 e-
|
|
12
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-59.4 e-
|
18.0 e-
|
|
13
|
45.8 e- / Vcal
|
0.2 e- / Vcal
|
34.2 e-
|
23.9 e-
|
|
14
|
46.0 e- / Vcal
|
0.1 e- / Vcal
|
37.9 e-
|
8.1 e-
|
|
15
|
51.3 e- / Vcal
|
0.2 e- / Vcal
|
-37.5 e-
|
20.0 e-
|
|
Average
|
46.4 e- / Vcal
|
|
-43.8 e-
|
|
|
Median
|
46.1 e- / Vcal
|
|
-37.5 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
