Test Date: 2015-10-26 13:54
Analysis date: 2015-12-09 17:54
Analysis date: 2015-12-09 17:54
M4076 XRayHRQualification
Summary
| Module | Module | M4076 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 42 | |
| BumpBondingDefects | Bump Bonding Defects | 42 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.12 | % |
| Noise | Mean Noise | 90 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.16 | 1.00 | 117.1 | 0 | 30.2 | 0/0 | 0 | 2078 | 48 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.99 | 1.37 | 125.1 | 0 | 32.3 | 0/0 | 0 | 2114 | 73 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 98.89 | 12.52 | 114.7 | 0 | 29.6 | 0/0 | 0 | 2062 | 36 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.25 | 0.96 | 181.3 | 0 | 47.0 | 0/0 | 0 | 2171 | 107 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.26 | 0.58 | 183.1 | 0 | 47.6 | 0/0 | 0 | 2180 | 112 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.25 | 0.77 | 202.3 | 0 | 52.6 | 0/0 | 0 | 2211 | 123 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.09 | 0.54 | 183.8 | 0 | 48.0 | 0/0 | 0 | 2178 | 107 | 0 |
|
Chip 7
|
A
|
25 | 0 | 99.88 | 99.18 | 0.74 | 189.6 | 25 | 49.3 | 0/0 | 0 | 2184 | 111 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.27 | 0.47 | 194.2 | 0 | 50.8 | 0/0 | 0 | 2220 | 128 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.05 | 0.59 | 187.5 | 0 | 49.0 | 0/0 | 0 | 2201 | 120 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.86 | 99.27 | 1.06 | 202.1 | 1 | 52.8 | 0/0 | 0 | 2196 | 117 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.03 | 0.66 | 186.7 | 0 | 48.6 | 0/0 | 0 | 2184 | 114 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.14 | 0.83 | 173.8 | 0 | 45.2 | 0/0 | 0 | 2151 | 93 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 98.97 | 13.41 | 114.8 | 0 | 29.8 | 0/0 | 0 | 2079 | 48 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.23 | 0.50 | 126.3 | 0 | 32.7 | 0/0 | 0 | 2072 | 43 | 0 |
|
Chip 15
|
A
|
16 | 0 | 99.85 | 98.94 | 1.13 | 118.6 | 16 | 30.6 | 0/0 | 0 | 2092 | 58 | 0 |
Errors
| nCriticals | # Criticals | 50 | |
| nErrors | # Errors | 2349 | |
| nWarnings | # Warnings | 1034 | |
| channel_0_count | Channel 0 | 824 | |
| channel_1_count | Channel 1 | 765 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 306 | |
| message_eventid_count | Event ID mismatch | 110 | |
| message_readback_count | Readback start marker | 1034 | |
| message_notokenpass_count | has NoTokenPass | 139 | |
| message_datasize_count | Data size criticals | 37 | |
| message_missingevents_count | Missing Event criticals | 13 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-111-gcc5e703 on branch 20151208_Readback
