Test Date: 2015-09-16 13:55
Analysis date: 2015-12-09 18:12
Analysis date: 2015-12-09 18:12
M4077 XRayHRQualification
Summary
| Module | Module | M4077 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.10 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.14 | 0.76 | 108.8 | 0 | 28.2 | 0/0 | 0 | 2020 | 167 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.17 | 0.76 | 114.1 | 0 | 29.6 | 0/0 | 0 | 2040 | 169 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.14 | 1.47 | 100.0 | 0 | 26.0 | 0/0 | 0 | 1996 | 160 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.27 | 0.63 | 164.8 | 0 | 42.9 | 0/0 | 0 | 2135 | 175 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.84 | 98.96 | 0.68 | 164.2 | 2 | 42.9 | 0/0 | 0 | 2108 | 170 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.24 | 0.41 | 183.8 | 0 | 48.0 | 0/0 | 0 | 2174 | 165 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.20 | 0.48 | 167.6 | 0 | 43.8 | 0/0 | 0 | 2122 | 158 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.85 | 98.98 | 0.66 | 176.5 | 1 | 46.1 | 0/0 | 0 | 2145 | 169 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 98.97 | 0.69 | 168.5 | 0 | 43.9 | 0/0 | 0 | 2110 | 168 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 98.99 | 0.78 | 166.9 | 0 | 43.5 | 0/0 | 0 | 2125 | 170 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.22 | 0.49 | 180.5 | 0 | 47.1 | 0/0 | 0 | 2153 | 169 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.00 | 0.70 | 160.8 | 0 | 41.9 | 0/0 | 0 | 2101 | 167 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.30 | 0.55 | 154.9 | 0 | 40.4 | 0/0 | 0 | 2116 | 173 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.23 | 0.96 | 101.3 | 0 | 26.4 | 0/0 | 0 | 1985 | 170 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 98.94 | 0.96 | 112.3 | 0 | 29.2 | 0/0 | 0 | 1994 | 167 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 98.92 | 1.32 | 111.4 | 0 | 29.0 | 0/0 | 0 | 2017 | 171 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 2178 | |
| nWarnings | # Warnings | 246 | |
| channel_0_count | Channel 0 | 483 | |
| channel_1_count | Channel 1 | 11 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 247 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 246 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-111-gcc5e703 on branch 20151208_Readback
