Test Date: 2015-12-11 15:01
Analysis date: 2015-12-15 09:52
X-ray Calibration - Spectrum
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
49.3295 |
|
| medianSlope |
median Slope |
49.523 |
|
| minSlope |
min Slope |
46.015 |
|
| maxSlope |
max Slope |
53.322 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-102.7318125 |
|
| medianOffset |
median Offset |
-74.7725 |
|
| minOffset |
min Offset |
-230.651 |
|
| maxOffset |
max Offset |
5.373 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
1.5568125 |
|
| medianchi2 |
median chi2 |
0.424 |
|
| minchi2 |
min chi2 |
0.003 |
|
| maxchi2 |
max chi2 |
9.499 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
50.7 e- / Vcal
|
0.2 e- / Vcal
|
5.4 e-
|
19.6 e-
|
|
1
|
46.0 e- / Vcal
|
0.1 e- / Vcal
|
-36.4 e-
|
12.9 e-
|
|
2
|
46.3 e- / Vcal
|
0.2 e- / Vcal
|
-229.9 e-
|
23.5 e-
|
|
3
|
47.9 e- / Vcal
|
0.2 e- / Vcal
|
-229.5 e-
|
19.6 e-
|
|
4
|
50.6 e- / Vcal
|
0.2 e- / Vcal
|
-62.5 e-
|
17.8 e-
|
|
5
|
47.1 e- / Vcal
|
0.1 e- / Vcal
|
-230.7 e-
|
10.2 e-
|
|
6
|
49.7 e- / Vcal
|
0.1 e- / Vcal
|
-81.0 e-
|
10.9 e-
|
|
7
|
48.4 e- / Vcal
|
0.2 e- / Vcal
|
-118.6 e-
|
19.6 e-
|
|
8
|
51.7 e- / Vcal
|
0.1 e- / Vcal
|
-111.2 e-
|
10.9 e-
|
|
9
|
53.3 e- / Vcal
|
0.2 e- / Vcal
|
-59.4 e-
|
20.2 e-
|
|
10
|
49.4 e- / Vcal
|
0.2 e- / Vcal
|
-1.3 e-
|
17.8 e-
|
|
11
|
51.1 e- / Vcal
|
0.1 e- / Vcal
|
-170.6 e-
|
11.7 e-
|
|
12
|
50.8 e- / Vcal
|
0.1 e- / Vcal
|
-68.5 e-
|
11.1 e-
|
|
13
|
46.7 e- / Vcal
|
0.1 e- / Vcal
|
-57.1 e-
|
14.4 e-
|
|
14
|
53.2 e- / Vcal
|
0.1 e- / Vcal
|
-154.6 e-
|
11.2 e-
|
|
15
|
46.2 e- / Vcal
|
0.1 e- / Vcal
|
-37.9 e-
|
11.6 e-
|
|
Average
|
49.3 e- / Vcal
|
|
-102.7 e-
|
|
|
Median
|
100.2 e- / Vcal
|
|
-229.8 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
