Test Date: 2016-08-18 11:13
Analysis date: 2016-08-18 13:28
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.63525 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.63525 |
|
| medianSlope |
median Slope |
48.94 |
|
| minSlope |
min Slope |
44.085 |
|
| maxSlope |
max Slope |
51.951 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
13.27825 |
|
| medianOffset |
median Offset |
12.986 |
|
| minOffset |
min Offset |
-153.139 |
|
| maxOffset |
max Offset |
140.351 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
5.0556875 |
|
| medianchi2 |
median chi2 |
2.3015 |
|
| minchi2 |
min chi2 |
0.032 |
|
| maxchi2 |
max chi2 |
32.614 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
45.6 e- / Vcal
|
0.2 e- / Vcal
|
-65.6 e-
|
21.4 e-
|
|
1
|
49.8 e- / Vcal
|
0.1 e- / Vcal
|
50.0 e-
|
11.6 e-
|
|
2
|
50.2 e- / Vcal
|
0.2 e- / Vcal
|
83.7 e-
|
20.6 e-
|
|
3
|
47.4 e- / Vcal
|
0.2 e- / Vcal
|
-45.7 e-
|
18.5 e-
|
|
4
|
50.9 e- / Vcal
|
0.1 e- / Vcal
|
72.8 e-
|
9.5 e-
|
|
5
|
52.0 e- / Vcal
|
0.2 e- / Vcal
|
140.4 e-
|
17.6 e-
|
|
6
|
49.2 e- / Vcal
|
0.2 e- / Vcal
|
10.2 e-
|
17.7 e-
|
|
7
|
51.4 e- / Vcal
|
0.2 e- / Vcal
|
-11.8 e-
|
20.6 e-
|
|
8
|
51.6 e- / Vcal
|
0.2 e- / Vcal
|
71.8 e-
|
18.3 e-
|
|
9
|
45.6 e- / Vcal
|
0.2 e- / Vcal
|
-60.6 e-
|
20.6 e-
|
|
10
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
75.6 e-
|
9.1 e-
|
|
11
|
48.2 e- / Vcal
|
0.1 e- / Vcal
|
-153.1 e-
|
10.3 e-
|
|
12
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-6.9 e-
|
10.0 e-
|
|
13
|
50.0 e- / Vcal
|
0.2 e- / Vcal
|
-11.1 e-
|
22.0 e-
|
|
14
|
48.6 e- / Vcal
|
0.1 e- / Vcal
|
15.8 e-
|
11.2 e-
|
|
15
|
44.1 e- / Vcal
|
0.1 e- / Vcal
|
47.1 e-
|
16.5 e-
|
|
Average
|
48.6 e- / Vcal
|
|
13.3 e-
|
|
|
Median
|
102.9 e- / Vcal
|
|
60.0 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
