Test Date: 2016-08-18 11:13
Analysis date: 2016-08-18 13:35
Analysis date: 2016-08-18 13:35
M4334 XRayHRQualification
Summary
| Module | Module | M4334 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 92 | |
| BumpBondingDefects | Bump Bonding Defects | 80 | |
| NoisyPixels | Noisy Pixels | 11 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.71/99.00 | % |
| Noise | Mean Noise | 188 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.84 | 99.16 | 0.72 | 28.9 | 97.2 | 2 | 0/0 | 0 | 1965 | 186 | 0 |
|
Chip 1
|
A
|
3 | 0 | 99.82 | 98.91 | 0.84 | 31.1 | 105.3 | 3 | 0/0 | 0 | 2006 | 191 | 0 |
|
Chip 2
|
A
|
5 | 0 | 99.82 | 98.90 | 0.71 | 28.3 | 95.9 | 5 | 0/0 | 0 | 1942 | 181 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.81 | 98.97 | 0.79 | 47.3 | 154.8 | 1 | 0/0 | 0 | 2107 | 188 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.80 | 98.94 | 1.37 | 48.6 | 160.2 | 1 | 0/0 | 0 | 2108 | 185 | 1 |
|
Chip 5
|
A
|
4 | 0 | 99.85 | 99.26 | 1.1 | 57.8 | 186.8 | 4 | 0/0 | 0 | 2169 | 184 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.82 | 98.99 | 0.77 | 53.4 | 174.8 | 1 | 0/0 | 0 | 2179 | 174 | 1 |
|
Chip 7
|
A
|
3 | 0 | 99.84 | 99.28 | 0.8 | 55.2 | 182.4 | 3 | 0/0 | 0 | 2175 | 176 | 0 |
|
Chip 8
|
A
|
9 | 0 | 99.84 | 99.16 | 1.01 | 56.4 | 186.3 | 9 | 0/0 | 0 | 2171 | 190 | 0 |
|
Chip 9
|
A
|
12 | 0 | 99.83 | 99.27 | 0.47 | 54.4 | 177.8 | 12 | 0/0 | 0 | 2171 | 177 | 0 |
|
Chip 10
|
A
|
16 | 0 | 99.85 | 99.35 | 0.48 | 58.2 | 188.1 | 16 | 0/0 | 0 | 2175 | 180 | 0 |
|
Chip 11
|
A
|
5 | 0 | 99.86 | 99.30 | 0.55 | 48.8 | 160.8 | 4 | 0/0 | 0 | 2115 | 178 | 1 |
|
Chip 12
|
A
|
3 | 0 | 99.84 | 99.26 | 0.64 | 47.0 | 154.4 | 3 | 0/0 | 0 | 2110 | 182 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.80 | 98.91 | 0.71 | 29.2 | 99.5 | 1 | 0/0 | 0 | 2017 | 176 | 0 |
|
Chip 14
|
A
|
3 | 0 | 99.78 | 98.91 | 0.9 | 31.9 | 108.2 | 3 | 0/0 | 0 | 1988 | 194 | 0 |
|
Chip 15
|
B
|
20 | 0 | 97.95 | 97.39 | 3.84 | 29.5 | 99.6 | 12 | 0/0 | 0 | 1957 | 269 | 8 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-18 | |
| TestTime | Test Time | 11:13 | |
| TestDuration | Duration | 1:20:7 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1704 | |
| nWarnings | # Warnings | 2083 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 2083 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 231 | |
| message_readback_count | Readback start marker | 1852 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
