Test Date: 2016-08-18 11:13
Analysis date: 2016-08-18 13:34
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
45.903375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
45.903375 |
|
| medianSlope |
median Slope |
46.073 |
|
| minSlope |
min Slope |
43.134 |
|
| maxSlope |
max Slope |
49.275 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
61.5030625 |
|
| medianOffset |
median Offset |
54.3325 |
|
| minOffset |
min Offset |
-79.114 |
|
| maxOffset |
max Offset |
391.993 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
8.05266666667 |
|
| medianchi2 |
median chi2 |
0.367 |
|
| minchi2 |
min chi2 |
0.011 |
|
| maxchi2 |
max chi2 |
91.313 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.7 e- / Vcal
|
0.2 e- / Vcal
|
41.2 e-
|
19.6 e-
|
|
1
|
43.1 e- / Vcal
|
0.1 e- / Vcal
|
1.4 e-
|
12.2 e-
|
|
2
|
46.4 e- / Vcal
|
0.2 e- / Vcal
|
67.4 e-
|
22.6 e-
|
|
3
|
43.6 e- / Vcal
|
0.2 e- / Vcal
|
-79.1 e-
|
19.7 e-
|
|
4
|
44.9 e- / Vcal
|
0.1 e- / Vcal
|
67.5 e-
|
12.9 e-
|
|
5
|
44.2 e- / Vcal
|
0.1 e- / Vcal
|
35.3 e-
|
17.4 e-
|
|
6
|
43.9 e- / Vcal
|
0.1 e- / Vcal
|
392.0 e-
|
11.5 e-
|
|
7
|
45.0 e- / Vcal
|
0.1 e- / Vcal
|
119.4 e-
|
10.3 e-
|
|
8
|
45.1 e- / Vcal
|
0.2 e- / Vcal
|
142.7 e-
|
19.2 e-
|
|
9
|
46.9 e- / Vcal
|
0.2 e- / Vcal
|
-14.2 e-
|
20.4 e-
|
|
10
|
46.8 e- / Vcal
|
0.1 e- / Vcal
|
106.2 e-
|
10.8 e-
|
|
11
|
47.4 e- / Vcal
|
0.1 e- / Vcal
|
-29.9 e-
|
11.2 e-
|
|
12
|
47.0 e- / Vcal
|
0.2 e- / Vcal
|
93.7 e-
|
19.7 e-
|
|
13
|
47.5 e- / Vcal
|
0.2 e- / Vcal
|
96.7 e-
|
21.8 e-
|
|
14
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
9.0 e-
|
12.2 e-
|
|
15
|
49.3 e- / Vcal
|
0.2 e- / Vcal
|
-65.2 e-
|
22.0 e-
|
|
Average
|
45.9 e- / Vcal
|
|
61.5 e-
|
|
|
Median
|
90.1 e- / Vcal
|
|
262.0 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
