Test Date: 2016-08-18 13:47
Analysis date: 2016-08-18 15:22
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
44.86225 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
44.86225 |
|
| medianSlope |
median Slope |
44.973 |
|
| minSlope |
min Slope |
42.729 |
|
| maxSlope |
max Slope |
48.113 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-9.2355625 |
|
| medianOffset |
median Offset |
8.084 |
|
| minOffset |
min Offset |
-152.047 |
|
| maxOffset |
max Offset |
145.479 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.5416875 |
|
| medianchi2 |
median chi2 |
0.4255 |
|
| minchi2 |
min chi2 |
0.067 |
|
| maxchi2 |
max chi2 |
15.855 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
-130.9 e-
|
11.5 e-
|
|
1
|
44.8 e- / Vcal
|
0.1 e- / Vcal
|
-93.8 e-
|
19.4 e-
|
|
2
|
43.1 e- / Vcal
|
0.2 e- / Vcal
|
145.5 e-
|
21.2 e-
|
|
3
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
-152.0 e-
|
10.4 e-
|
|
4
|
44.5 e- / Vcal
|
0.2 e- / Vcal
|
-128.7 e-
|
19.8 e-
|
|
5
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-63.3 e-
|
18.2 e-
|
|
6
|
43.8 e- / Vcal
|
0.1 e- / Vcal
|
20.4 e-
|
9.0 e-
|
|
7
|
43.1 e- / Vcal
|
0.1 e- / Vcal
|
108.4 e-
|
11.7 e-
|
|
8
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
-56.1 e-
|
8.9 e-
|
|
9
|
45.4 e- / Vcal
|
0.1 e- / Vcal
|
19.1 e-
|
8.7 e-
|
|
10
|
48.1 e- / Vcal
|
0.1 e- / Vcal
|
53.0 e-
|
16.5 e-
|
|
11
|
46.3 e- / Vcal
|
0.2 e- / Vcal
|
-83.0 e-
|
20.0 e-
|
|
12
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
40.0 e-
|
17.6 e-
|
|
13
|
44.5 e- / Vcal
|
0.2 e- / Vcal
|
104.4 e-
|
22.6 e-
|
|
14
|
45.3 e- / Vcal
|
0.1 e- / Vcal
|
72.2 e-
|
9.3 e-
|
|
15
|
42.7 e- / Vcal
|
0.1 e- / Vcal
|
-2.9 e-
|
18.8 e-
|
|
Average
|
44.9 e- / Vcal
|
|
-9.2 e-
|
|
|
Median
|
88.2 e- / Vcal
|
|
52.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
