Test Date: 2016-08-18 13:47
Analysis date: 2016-08-18 15:30
Analysis date: 2016-08-18 15:30
M4419 XRayHRQualification
Summary
| Module | Module | M4419 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 61 | |
| BumpBondingDefects | Bump Bonding Defects | 51 | |
| NoisyPixels | Noisy Pixels | 10 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 50/120 | 99.85/99.12 | % |
| Noise | Mean Noise | 168 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.81 | 98.93 | 0.89 | 27.0 | 91.9 | 0 | 0/0 | 0 | 2008 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.93 | 0.83 | 30.8 | 104.7 | 0 | 0/0 | 0 | 2022 | 187 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 98.96 | 0.42 | 27.1 | 93.0 | 0 | 0/0 | 0 | 1971 | 181 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.15 | 0.83 | 46.5 | 152.2 | 0 | 0/0 | 0 | 2139 | 164 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.83 | 98.95 | 1.13 | 48.0 | 158.4 | 1 | 0/0 | 0 | 2133 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.83 | 98.99 | 1.02 | 57.2 | 184.7 | 0 | 0/0 | 0 | 2188 | 157 | 0 |
|
Chip 6
|
C
|
3 | 0 | 99.87 | 99.27 | 0.74 | 56.9 | 184.7 | 0 | 0/0 | 0+4/0 | 2124 | 171 | 3 |
|
Chip 7
|
A
|
7 | 0 | 99.87 | 99.32 | 0.78 | 55.9 | 184.2 | 1 | 0/0 | 0 | 1952 | 157 | 6 |
|
Chip 8
|
A
|
7 | 0 | 99.88 | 99.30 | 0.6 | 57.4 | 189.1 | 6 | 0/0 | 0 | 2161 | 162 | 1 |
|
Chip 9
|
A
|
11 | 0 | 99.86 | 99.30 | 0.66 | 56.9 | 185.3 | 11 | 0/0 | 0 | 2209 | 160 | 0 |
|
Chip 10
|
A
|
6 | 0 | 99.85 | 99.28 | 0.6 | 60.9 | 195.8 | 6 | 0/0 | 0 | 2241 | 163 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.22 | 1.42 | 48.7 | 161.0 | 0 | 0/0 | 0 | 2168 | 163 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.83 | 99.04 | 0.91 | 46.7 | 153.7 | 0 | 0/0 | 0 | 2146 | 166 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.83 | 98.94 | 0.67 | 28.3 | 97.0 | 1 | 0/0 | 0 | 2027 | 172 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.24 | 0.56 | 30.4 | 104.0 | 0 | 0/0 | 0 | 2041 | 175 | 0 |
|
Chip 15
|
A
|
25 | 0 | 99.86 | 99.15 | 0.7 | 28.2 | 96.1 | 25 | 0/0 | 0 | 2012 | 170 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-08-18 | |
| TestTime | Test Time | 13:47 | |
| TestDuration | Duration | 1:19:43 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
