Test Date: 2016-08-18 13:47
Analysis date: 2016-08-18 15:32
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
45.8668125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
45.8668125 |
|
| medianSlope |
median Slope |
45.9885 |
|
| minSlope |
min Slope |
41.502 |
|
| maxSlope |
max Slope |
49.213 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-8.2810625 |
|
| medianOffset |
median Offset |
15.608 |
|
| minOffset |
min Offset |
-139.215 |
|
| maxOffset |
max Offset |
203.753 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
1.8674375 |
|
| medianchi2 |
median chi2 |
0.513 |
|
| minchi2 |
min chi2 |
0.018 |
|
| maxchi2 |
max chi2 |
12.394 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
49.2 e- / Vcal
|
0.2 e- / Vcal
|
87.6 e-
|
22.5 e-
|
|
1
|
48.7 e- / Vcal
|
0.2 e- / Vcal
|
43.7 e-
|
23.0 e-
|
|
2
|
42.3 e- / Vcal
|
0.2 e- / Vcal
|
-98.1 e-
|
21.5 e-
|
|
3
|
43.8 e- / Vcal
|
0.1 e- / Vcal
|
25.1 e-
|
9.5 e-
|
|
4
|
43.3 e- / Vcal
|
0.1 e- / Vcal
|
65.2 e-
|
10.0 e-
|
|
5
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
105.1 e-
|
9.6 e-
|
|
6
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
-117.7 e-
|
18.6 e-
|
|
7
|
47.8 e- / Vcal
|
0.1 e- / Vcal
|
-112.2 e-
|
11.4 e-
|
|
8
|
46.3 e- / Vcal
|
0.1 e- / Vcal
|
-109.2 e-
|
11.7 e-
|
|
9
|
49.2 e- / Vcal
|
0.1 e- / Vcal
|
85.0 e-
|
16.8 e-
|
|
10
|
41.5 e- / Vcal
|
0.1 e- / Vcal
|
6.1 e-
|
9.9 e-
|
|
11
|
45.6 e- / Vcal
|
0.1 e- / Vcal
|
-139.2 e-
|
13.0 e-
|
|
12
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
32.7 e-
|
17.5 e-
|
|
13
|
46.8 e- / Vcal
|
0.2 e- / Vcal
|
203.8 e-
|
21.0 e-
|
|
14
|
46.9 e- / Vcal
|
0.2 e- / Vcal
|
-112.9 e-
|
20.4 e-
|
|
15
|
44.4 e- / Vcal
|
0.2 e- / Vcal
|
-97.4 e-
|
21.5 e-
|
|
Average
|
45.9 e- / Vcal
|
|
-8.3 e-
|
|
|
Median
|
94.1 e- / Vcal
|
|
-221.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
