Test Date: 2015-11-03 12:52
Analysis date: 2015-11-23 15:58
X-ray Calibration - Spectrum
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.2785 |
|
| medianSlope |
median Slope |
46.644 |
|
| minSlope |
min Slope |
42.356 |
|
| maxSlope |
max Slope |
48.724 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-61.3325 |
|
| medianOffset |
median Offset |
-59.6675 |
|
| minOffset |
min Offset |
-151.469 |
|
| maxOffset |
max Offset |
79.033 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.6459375 |
|
| medianchi2 |
median chi2 |
1.0845 |
|
| minchi2 |
min chi2 |
0.026 |
|
| maxchi2 |
max chi2 |
11.355 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.9 e- / Vcal
|
0.2 e- / Vcal
|
-23.4 e-
|
20.4 e-
|
|
1
|
42.9 e- / Vcal
|
0.1 e- / Vcal
|
15.1 e-
|
7.7 e-
|
|
2
|
45.2 e- / Vcal
|
0.2 e- / Vcal
|
79.0 e-
|
21.7 e-
|
|
3
|
46.5 e- / Vcal
|
0.1 e- / Vcal
|
-31.5 e-
|
6.8 e-
|
|
4
|
47.2 e- / Vcal
|
0.1 e- / Vcal
|
-51.9 e-
|
6.2 e-
|
|
5
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
-111.3 e-
|
7.6 e-
|
|
6
|
46.6 e- / Vcal
|
0.2 e- / Vcal
|
-95.2 e-
|
18.8 e-
|
|
7
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
-151.5 e-
|
6.2 e-
|
|
8
|
46.6 e- / Vcal
|
0.1 e- / Vcal
|
-92.8 e-
|
6.9 e-
|
|
9
|
48.7 e- / Vcal
|
0.1 e- / Vcal
|
-7.1 e-
|
16.8 e-
|
|
10
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
-54.9 e-
|
6.1 e-
|
|
11
|
47.6 e- / Vcal
|
0.1 e- / Vcal
|
-64.4 e-
|
17.4 e-
|
|
12
|
48.3 e- / Vcal
|
0.1 e- / Vcal
|
-30.1 e-
|
6.2 e-
|
|
13
|
47.9 e- / Vcal
|
0.1 e- / Vcal
|
-109.9 e-
|
13.0 e-
|
|
14
|
48.0 e- / Vcal
|
0.2 e- / Vcal
|
-128.9 e-
|
19.0 e-
|
|
15
|
42.4 e- / Vcal
|
0.1 e- / Vcal
|
-122.4 e-
|
6.6 e-
|
|
Average
|
46.3 e- / Vcal
|
|
-61.3 e-
|
|
|
Median
|
46.6 e- / Vcal
|
|
-54.9 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
