Test Date: 2016-04-25 14:49
Analysis date: 2016-04-25 16:42
Analysis date: 2016-04-25 16:42
M3632 XRayHRQualification
Summary
| Module | Module | M3632 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.84/99.07 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.83 | 98.90 | 0.69 | 33.0 | 87.0 | 0 | 0/0 | 0 | 1963 | 156 | 1 |
|
Chip 1
|
A
|
1 | 0 | 99.83 | 98.91 | 0.84 | 36.5 | 95.7 | 0 | 0/0 | 0 | 1992 | 159 | 1 |
|
Chip 2
|
A
|
1 | 0 | 99.85 | 99.01 | 0.55 | 32.2 | 84.2 | 0 | 0/0 | 0 | 1948 | 163 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.15 | 1.11 | 55.6 | 143.3 | 0 | 0/0 | 0 | 2118 | 161 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.19 | 0.59 | 58.9 | 151.1 | 0 | 0/0 | 0 | 2145 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 98.98 | 0.55 | 76.6 | 195.1 | 0 | 0/0 | 0 | 2205 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 98.97 | 1.15 | 68.1 | 173.7 | 0 | 0/0 | 0 | 2171 | 162 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.84 | 98.89 | 0.8 | 64.4 | 163.9 | 0 | 0/0 | 0 | 2180 | 155 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.84 | 99.00 | 0.74 | 72.8 | 185.8 | 0 | 0/0 | 0 | 2161 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.80 | 99.23 | 1.1 | 77.0 | 195.8 | 0 | 0/0 | 0 | 2208 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.21 | 0.66 | 75.3 | 191.1 | 0 | 0/0 | 0 | 2218 | 154 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.83 | 99.22 | 0.85 | 64.2 | 164.7 | 0 | 0/0 | 0 | 2170 | 152 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.83 | 99.12 | 0.63 | 59.5 | 153.3 | 0 | 0/0 | 0 | 2119 | 156 | 1 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.12 | 0.69 | 39.1 | 102.3 | 0 | 0/0 | 0 | 2036 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.23 | 0.56 | 39.1 | 102.4 | 0 | 0/0 | 0 | 2062 | 158 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.83 | 98.92 | 0.72 | 38.3 | 100.2 | 0 | 0/0 | 0 | 2047 | 160 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-04-25 | |
| TestTime | Test Time | 14:49 | |
| TestDuration | Duration | 1:9:59 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v0.7.3-14-g740d8b3 on branch psi46master
