Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Analysis date: 2019-05-03 15:24
Chip 0
Grading
| ROCGrade | Final ROC Grade | C | |
| NumberOfHotPixels | # Hot Pixels 300/100 | 4160/4160 | |
| NumberOfNonUniformColumns | # Non-Uniform Columns 300/100 | 52 | |
| NumberOfNonUniformEvents | # Non-Uniform ROC Events 300/100 | 0/0 | |
| NumberOfNonUniformColumnEvents | # Non-Uniform Col. Events 300/100 | 0/0 | |
| BadDoubleColumns | # Bad Double Columns | 26 | |
| BumpBondingDefects | # Bump Bonding Defects 300/100 | 0/0 | |
| Efficiency | Efficiency 50/120 | -1.0/-1.0 | |
| EfficiencyFit | Efficiency Fit | chi2/ndf: -1, # points: -1 | |
| EfficiencyGrade | Efficiency Grade 50/120 | (N/A)/N/A | |
| BadDoubleColumnsGrade | Bad DC Grade | C | |
| HotPixelsGrade | Hot Pixels Grade 300/100 | C/C | |
| HitMapGrade | Hit Map Grade 300/100 | A/A | |
| ReadoutUniformityOverTimeGrade | ROC Read. Unif. Grade 300/100 | A/A | |
| ColumnReadoutUniformityOverTimeGrade | Column Read. Unif. Grade 300/100 | A/A | |
| ColumnUniformityGrade | Column Uniformity Grade | C | |
| NoiseGrade | Noise Grade | C |
Efficiency Interpolation: C0
| fitfunction | Fit | [0]-[1]*x^3 | |
| BadDoubleColumns | # Bad DCs (excluded from fit) | 26 | |
| InterpolatedEfficiency50 | Interpol. Efficiency 50 | -1.00 | |
| InterpolatedEfficiency120 | Interpol. Efficiency 120 | -1.00 |
Hit Map 300: C0
| RealHitrate | Real Hitrate | 0.00 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 4160 |
Hit Map 100: C0
| RealHitrate | Real Hitrate | 0.00 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 4160 |
Read. Unif. over Time 300: C0
Time unif. distribution 300: C0
| chi2/ndf | chi2/ndf | 3.94 | |
| sigma | σ | 0.00 | |
| sigma_th | σ_th | 0.00 | |
| expectation | Red curve (expected) | Poisson |
Read. Unif. over Time 100: C0
Time unif. distribution 100: C0
| chi2/ndf | chi2/ndf | 3.94 | |
| sigma | σ | 0.00 | |
| sigma_th | σ_th | 0.00 | |
| expectation | Red curve (expected) | Poisson |
Col. Uniformity per Event: C0 300
| mu | μ | 0.00 | |
| sigma | fit error of μ | 0.00 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
Col. Uniformity per Event: C0 100
| mu | μ | 0.00 | |
| sigma | fit error of μ | 0.00 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
S-Curve widths: Noise (e^{-}) C0 250
| N | N | 113 | |
| mu | μ | 703.41 | |
| sigma | RMS | 392.77 | |
| threshold | thr | -7737981893990387647729455686024807636895839651402580770967127295387957590526272055192490212857071697298347097360926753628519365552856072210874368.00 | |
| fit | fit | Gaussian | |
| fit_peak | μ fit | 30.00 | |
| fit_sigma | σ fit | -5645.56 | |
| MeasuredHitrate | Measured hitrate: | 74.4 | |
| under | <= | 2660.00 | |
| over | >= | 1387.00 |
DC Efficiency Distribution: C0
| MeanEfficiency_50 | Mean Efficiency 50 MHz/cm2 | 0.00 | |
| MeanEfficiency_120 | Mean Efficiency 120 MHz/cm2 | 0.00 | |
| NBadDoubleColumns | Bad Double Columns | -1 |
