Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Analysis date: 2019-05-03 15:24
Chip 1
Grading
| ROCGrade | Final ROC Grade | C | |
| NumberOfHotPixels | # Hot Pixels 300/100 | 0/0 | |
| NumberOfNonUniformColumns | # Non-Uniform Columns 300/100 | 0 | |
| NumberOfNonUniformEvents | # Non-Uniform ROC Events 300/100 | 89/0 | |
| NumberOfNonUniformColumnEvents | # Non-Uniform Col. Events 300/100 | 3542/0 | |
| BadDoubleColumns | # Bad Double Columns | 0 | |
| BumpBondingDefects | # Bump Bonding Defects 300/100 | 0/0 | |
| Efficiency | Efficiency 50/120 | 99.89/99.79 | |
| EfficiencyFit | Efficiency Fit | chi2/ndf: 0.22, # points: 65 | |
| EfficiencyGrade | Efficiency Grade 50/120 | (A)/A | |
| BadDoubleColumnsGrade | Bad DC Grade | A | |
| HotPixelsGrade | Hot Pixels Grade 300/100 | A/A | |
| HitMapGrade | Hit Map Grade 300/100 | A/A | |
| ReadoutUniformityOverTimeGrade | ROC Read. Unif. Grade 300/100 | C/A | |
| ColumnReadoutUniformityOverTimeGrade | Column Read. Unif. Grade 300/100 | C/A | |
| ColumnUniformityGrade | Column Uniformity Grade | A | |
| NoiseGrade | Noise Grade | A |
Efficiency Interpolation: C1
| fitfunction | Fit | [0]-[1]*x^3 | |
| BadDoubleColumns | # Bad DCs (excluded from fit) | 0 | |
| Chi2NDF | chi2/ndf | 0.22 | |
| NumberFitPoints | # fit points | 65 | |
| p0 | p0 | 99.90 | |
| p1 | p1 | 6.27e-08 | |
| InterpolatedEfficiency50 | Interpol. Efficiency 50 | 99.89 | |
| InterpolatedEfficiency120 | Interpol. Efficiency 120 | 99.79 |
Hit Map 300: C1
| RealHitrate | Real Hitrate | 231.89 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Hit Map 100: C1
| RealHitrate | Real Hitrate | 78.48 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Col. Read. Unif. 300: C1
Col. Read. Unif. 100: C1
Read. Unif. over Time 300: C1
Time unif. distribution 300: C1
| chi2/ndf | chi2/ndf | 76.59 | |
| sigma | σ | 2139.90 | |
| sigma_th | σ_th | 87.22 | |
| expectation | Red curve (expected) | Poisson |
Read. Unif. over Time 100: C1
Time unif. distribution 100: C1
| chi2/ndf | chi2/ndf | 1.00 | |
| sigma | σ | 54.13 | |
| sigma_th | σ_th | 50.74 | |
| expectation | Red curve (expected) | Poisson |
Col. Uniformity per Event: C1 300
| mu | μ | 24.68 | |
| sigma | fit error of μ | 2.13 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 3542 |
Col. Uniformity per Event: C1 100
| mu | μ | 24.36 | |
| sigma | fit error of μ | 2.12 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
S-Curve widths: Noise (e^{-}) C1 250
| N | N | 3949 | |
| mu | μ | 251.62 | |
| sigma | RMS | 114.12 | |
| threshold | thr | 2199.87 | |
| fit | fit | Gaussian | |
| fit_peak | μ fit | 252.24 | |
| fit_sigma | σ fit | 66.87 | |
| MeasuredHitrate | Measured hitrate: | 74.4 | |
| under | <= | 158.00 | |
| over | >= | 53.00 |
DC Efficiency Distribution: C1
| MeanEfficiency_50 | Mean Efficiency 50 MHz/cm2 | 99.91 | |
| MeanEfficiency_120 | Mean Efficiency 120 MHz/cm2 | 99.78 | |
| NBadDoubleColumns | Bad Double Columns | 0 |
