Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 10
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.9/99.8
EfficiencyFit Efficiency Fit chi2/ndf: 0.20, # points: 63
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C10
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.20
NumberFitPoints # fit points 63
p0 p0 99.91
p1 p1 6.43e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.90
InterpolatedEfficiency120 Interpol. Efficiency 120 99.80
Efficiency Map 50: C10
Efficiency Map 100: C10
Efficiency Map 150: C10
Efficiency Map 200: C10
Efficiency Map 250: C10
Efficiency Map 300: C10
Efficiency Map 400: C10
Efficiency Distr. 50: C10
Plot
N N 4160
mu μ 99.93
sigma σ 0.37
Efficiency Distr. 100: C10
Plot
N N 4160
mu μ 99.86
sigma σ 0.54
Efficiency Distr. 150: C10
Plot
N N 4160
mu μ 99.78
sigma σ 0.67
Efficiency Distr. 200: C10
Plot
N N 4160
mu μ 99.68
sigma σ 0.81
Efficiency Distr. 250: C10
Plot
N N 4160
mu μ 99.61
sigma σ 0.91
Efficiency Distr. 300: C10
Plot
N N 4160
mu μ 99.50
sigma σ 1.01
Efficiency Distr. 400: C10
Plot
N N 4160
mu μ 99.33
sigma σ 1.19
Background Map 50: C10
Plot
RealHitrate Real Hitrate 40.53 MHz/cm2
Background Map 100: C10
Plot
RealHitrate Real Hitrate 82.93 MHz/cm2
Background Map 150: C10
Plot
RealHitrate Real Hitrate 125.89 MHz/cm2
Background Map 200: C10
Plot
RealHitrate Real Hitrate 170.60 MHz/cm2
Background Map 250: C10
Plot
RealHitrate Real Hitrate 216.89 MHz/cm2
Background Map 300: C10
Plot
RealHitrate Real Hitrate 261.04 MHz/cm2
Background Map 400: C10
Plot
RealHitrate Real Hitrate 324.91 MHz/cm2
Retrim Hot Pix 150: C10
Retrim Hot Pix 50: C10
Masked Hot Pixels 300: C10
Masked Hot Pixels 100: C10
Hit Map 300: C10
Plot
RealHitrate Real Hitrate 258.88 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C10
Hit Map 100: C10
Plot
RealHitrate Real Hitrate 80.42 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C10
Col. Read. Unif. 300: C10
Plot
N N 7445135
mu μ 160977
sigma σ 41247.68
Col. Read. Unif. 100: C10
Plot
N N 2312475
mu μ 50021
sigma σ 12850.98
Read. Unif. over Time 300: C10
Plot
N N 8370801
mu μ 8490
sigma_th σ_th 92.14
Time unif. distribution 300: C10
Plot
chi2/ndf chi2/ndf 7.52
sigma σ 110.69
sigma_th σ_th 92.15
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C10
Plot
N N 2601092
mu μ 2638
sigma_th σ_th 51.36
Time unif. distribution 100: C10
Plot
chi2/ndf chi2/ndf 0.97
sigma σ 53.70
sigma_th σ_th 51.36
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C10
Col. Uniformity per Event: C10 300
Plot
mu μ 28.14
sigma fit error of μ 2.15
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C10 100
Plot
mu μ 28.20
sigma fit error of μ 2.19
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C10 250
Plot
N N 3955
mu μ 322.36
sigma RMS 116.69
threshold thr 1143.55
fit fit Gaussian
fit_peak μ fit 305.41
fit_sigma σ fit 71.83
MeasuredHitrate Measured hitrate: 74.4
under <= 159.00
over >= 46.00
Alive Map: C10
DC Efficiency Distribution: C10
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.91
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.80
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C10
