Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 12
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 85/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 1462/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/1
Efficiency Efficiency 50/120 99.91/99.81
EfficiencyFit Efficiency Fit chi2/ndf: 0.18, # points: 92
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 C/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 C/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C12
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.18
NumberFitPoints # fit points 92
p0 p0 99.92
p1 p1 6.31e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.91
InterpolatedEfficiency120 Interpol. Efficiency 120 99.81
Efficiency Map 50: C12
Efficiency Map 100: C12
Efficiency Map 150: C12
Efficiency Map 200: C12
Efficiency Map 250: C12
Efficiency Map 300: C12
Efficiency Map 400: C12
Efficiency Distr. 50: C12
Plot
N N 4160
mu μ 99.95
sigma σ 0.32
Efficiency Distr. 100: C12
Plot
N N 4160
mu μ 99.91
sigma σ 0.42
Efficiency Distr. 150: C12
Plot
N N 4160
mu μ 99.86
sigma σ 0.52
Efficiency Distr. 200: C12
Plot
N N 4160
mu μ 99.81
sigma σ 0.63
Efficiency Distr. 250: C12
Plot
N N 4160
mu μ 99.74
sigma σ 0.78
Efficiency Distr. 300: C12
Plot
N N 4160
mu μ 99.69
sigma σ 0.82
Efficiency Distr. 400: C12
Plot
N N 4160
mu μ 99.62
sigma σ 0.91
Background Map 50: C12
Plot
RealHitrate Real Hitrate 27.79 MHz/cm2
Background Map 100: C12
Plot
RealHitrate Real Hitrate 56.26 MHz/cm2
Background Map 150: C12
Plot
RealHitrate Real Hitrate 85.24 MHz/cm2
Background Map 200: C12
Plot
RealHitrate Real Hitrate 114.57 MHz/cm2
Background Map 250: C12
Plot
RealHitrate Real Hitrate 143.90 MHz/cm2
Background Map 300: C12
Plot
RealHitrate Real Hitrate 173.97 MHz/cm2
Background Map 400: C12
Plot
RealHitrate Real Hitrate 217.39 MHz/cm2
Retrim Hot Pix 150: C12
Retrim Hot Pix 50: C12
Masked Hot Pixels 300: C12
Masked Hot Pixels 100: C12
Hit Map 300: C12
Plot
RealHitrate Real Hitrate 159.42 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C12
Hit Map 100: C12
Plot
RealHitrate Real Hitrate 54.83 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 1
BB Defects 100: C12
Col. Read. Unif. 300: C12
Plot
N N 4571352
mu μ 99130
sigma σ 37486.04
Col. Read. Unif. 100: C12
Plot
N N 1576925
mu μ 34106
sigma σ 12467.74
Read. Unif. over Time 300: C12
Plot
N N 5154782
mu μ 5228
sigma_th σ_th 72.30
Time unif. distribution 300: C12
Plot
chi2/ndf chi2/ndf 66.06
sigma σ 1549.15
sigma_th σ_th 72.31
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C12
Plot
N N 1773491
mu μ 1799
sigma_th σ_th 42.41
Time unif. distribution 100: C12
Plot
chi2/ndf chi2/ndf 1.23
sigma σ 43.52
sigma_th σ_th 42.41
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C12
Col. Uniformity per Event: C12 300
Plot
mu μ 29.84
sigma fit error of μ 2.22
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 1462
Col. Uniformity per Event: C12 100
Plot
mu μ 29.53
sigma fit error of μ 2.20
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C12 250
Plot
N N 3956
mu μ 295.45
sigma RMS 95.69
threshold thr 1315.80
fit fit Gaussian
fit_peak μ fit 284.30
fit_sigma σ fit 49.85
MeasuredHitrate Measured hitrate: 74.4
under <= 153.00
over >= 51.00
Alive Map: C12
DC Efficiency Distribution: C12
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.92
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.81
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C12
