Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 15
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.89/99.79
EfficiencyFit Efficiency Fit chi2/ndf: 0.27, # points: 66
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C15
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.27
NumberFitPoints # fit points 66
p0 p0 99.90
p1 p1 6.61e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.89
InterpolatedEfficiency120 Interpol. Efficiency 120 99.79
Efficiency Map 50: C15
Efficiency Map 100: C15
Efficiency Map 150: C15
Efficiency Map 200: C15
Efficiency Map 250: C15
Efficiency Map 300: C15
Efficiency Map 400: C15
Efficiency Distr. 50: C15
Plot
N N 4160
mu μ 99.91
sigma σ 0.44
Efficiency Distr. 100: C15
Plot
N N 4160
mu μ 99.84
sigma σ 0.58
Efficiency Distr. 150: C15
Plot
N N 4160
mu μ 99.72
sigma σ 0.74
Efficiency Distr. 200: C15
Plot
N N 4160
mu μ 99.66
sigma σ 0.84
Efficiency Distr. 250: C15
Plot
N N 4160
mu μ 99.49
sigma σ 1.03
Efficiency Distr. 300: C15
Plot
N N 4160
mu μ 99.38
sigma σ 1.15
Efficiency Distr. 400: C15
Plot
N N 4160
mu μ 99.20
sigma σ 1.30
Background Map 50: C15
Plot
RealHitrate Real Hitrate 44.16 MHz/cm2
Background Map 100: C15
Plot
RealHitrate Real Hitrate 90.28 MHz/cm2
Background Map 150: C15
Plot
RealHitrate Real Hitrate 137.18 MHz/cm2
Background Map 200: C15
Plot
RealHitrate Real Hitrate 185.14 MHz/cm2
Background Map 250: C15
Plot
RealHitrate Real Hitrate 234.36 MHz/cm2
Background Map 300: C15
Plot
RealHitrate Real Hitrate 282.30 MHz/cm2
Background Map 400: C15
Plot
RealHitrate Real Hitrate 337.28 MHz/cm2
Retrim Hot Pix 150: C15
Retrim Hot Pix 50: C15
Masked Hot Pixels 300: C15
Masked Hot Pixels 100: C15
Hit Map 300: C15
Plot
RealHitrate Real Hitrate 279.80 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C15
Hit Map 100: C15
Plot
RealHitrate Real Hitrate 87.43 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C15
Col. Read. Unif. 300: C15
Plot
N N 8082044
mu μ 173987
sigma σ 30849.37
Col. Read. Unif. 100: C15
Plot
N N 2529577
mu μ 54379
sigma σ 9493.94
Read. Unif. over Time 300: C15
Plot
N N 9047329
mu μ 9176
sigma_th σ_th 95.79
Time unif. distribution 300: C15
Plot
chi2/ndf chi2/ndf 5.86
sigma σ 113.36
sigma_th σ_th 95.81
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C15
Plot
N N 2827728
mu μ 2868
sigma_th σ_th 53.55
Time unif. distribution 100: C15
Plot
chi2/ndf chi2/ndf 1.30
sigma σ 58.18
sigma_th σ_th 53.55
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C15
Col. Uniformity per Event: C15 300
Plot
mu μ 26.43
sigma fit error of μ 2.18
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C15 100
Plot
mu μ 26.14
sigma fit error of μ 2.17
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C15 250
Plot
N N 3953
mu μ 316.89
sigma RMS 106.78
threshold thr 1503.92
fit fit Gaussian
fit_peak μ fit 304.55
fit_sigma σ fit 67.26
MeasuredHitrate Measured hitrate: 74.4
under <= 155.00
over >= 52.00
Alive Map: C15
DC Efficiency Distribution: C15
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.90
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.78
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C15
