Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 3
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.89/99.8
EfficiencyFit Efficiency Fit chi2/ndf: 0.25, # points: 92
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C3
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.25
NumberFitPoints # fit points 92
p0 p0 99.90
p1 p1 5.47e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.89
InterpolatedEfficiency120 Interpol. Efficiency 120 99.80
Efficiency Map 50: C3
Efficiency Map 100: C3
Efficiency Map 150: C3
Efficiency Map 200: C3
Efficiency Map 250: C3
Efficiency Map 300: C3
Efficiency Map 400: C3
Efficiency Distr. 50: C3
Plot
N N 4160
mu μ 99.95
sigma σ 0.32
Efficiency Distr. 100: C3
Plot
N N 4160
mu μ 99.88
sigma σ 0.48
Efficiency Distr. 150: C3
Plot
N N 4160
mu μ 99.82
sigma σ 0.59
Efficiency Distr. 200: C3
Plot
N N 4160
mu μ 99.76
sigma σ 0.71
Efficiency Distr. 250: C3
Plot
N N 4160
mu μ 99.72
sigma σ 0.77
Efficiency Distr. 300: C3
Plot
N N 4160
mu μ 99.66
sigma σ 0.85
Efficiency Distr. 400: C3
Plot
N N 4160
mu μ 99.49
sigma σ 1.07
Background Map 50: C3
Plot
RealHitrate Real Hitrate 30.11 MHz/cm2
Background Map 100: C3
Plot
RealHitrate Real Hitrate 61.36 MHz/cm2
Background Map 150: C3
Plot
RealHitrate Real Hitrate 93.26 MHz/cm2
Background Map 200: C3
Plot
RealHitrate Real Hitrate 125.09 MHz/cm2
Background Map 250: C3
Plot
RealHitrate Real Hitrate 157.33 MHz/cm2
Background Map 300: C3
Plot
RealHitrate Real Hitrate 188.51 MHz/cm2
Background Map 400: C3
Plot
RealHitrate Real Hitrate 235.96 MHz/cm2
Retrim Hot Pix 150: C3
Retrim Hot Pix 50: C3
Masked Hot Pixels 300: C3
Masked Hot Pixels 100: C3
Hit Map 300: C3
Plot
RealHitrate Real Hitrate 184.99 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C3
Hit Map 100: C3
Plot
RealHitrate Real Hitrate 59.39 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C3
Col. Read. Unif. 300: C3
Plot
N N 5279903
mu μ 115035
sigma σ 46698.24
Col. Read. Unif. 100: C3
Plot
N N 1697606
mu μ 36942
sigma σ 14775.50
Read. Unif. over Time 300: C3
Plot
N N 5981844
mu μ 6067
sigma_th σ_th 77.89
Time unif. distribution 300: C3
Plot
chi2/ndf chi2/ndf 4.16
sigma σ 89.44
sigma_th σ_th 77.90
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C3
Plot
N N 1920958
mu μ 1948
sigma_th σ_th 44.14
Time unif. distribution 100: C3
Plot
chi2/ndf chi2/ndf 1.32
sigma σ 45.62
sigma_th σ_th 44.14
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C3
Col. Uniformity per Event: C3 300
Plot
mu μ 22.19
sigma fit error of μ 2.22
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C3 100
Plot
mu μ 22.43
sigma fit error of μ 2.21
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C3 250
Plot
N N 3958
mu μ 324.25
sigma RMS 104.12
threshold thr 887.76
fit fit Gaussian
fit_peak μ fit 312.13
fit_sigma σ fit 63.77
MeasuredHitrate Measured hitrate: 74.4
under <= 152.00
over >= 50.00
Alive Map: C3
DC Efficiency Distribution: C3
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.91
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.80
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C3
