Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 6
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.9/99.81
EfficiencyFit Efficiency Fit chi2/ndf: 0.25, # points: 64
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C6
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.25
NumberFitPoints # fit points 64
p0 p0 99.91
p1 p1 5.96e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.90
InterpolatedEfficiency120 Interpol. Efficiency 120 99.81
Efficiency Map 50: C6
Efficiency Map 100: C6
Efficiency Map 150: C6
Efficiency Map 200: C6
Efficiency Map 250: C6
Efficiency Map 300: C6
Efficiency Map 400: C6
Efficiency Distr. 50: C6
Plot
N N 4160
mu μ 99.92
sigma σ 0.40
Efficiency Distr. 100: C6
Plot
N N 4160
mu μ 99.84
sigma σ 0.57
Efficiency Distr. 150: C6
Plot
N N 4160
mu μ 99.74
sigma σ 0.74
Efficiency Distr. 200: C6
Plot
N N 4160
mu μ 99.65
sigma σ 0.85
Efficiency Distr. 250: C6
Plot
N N 4160
mu μ 99.52
sigma σ 1.00
Efficiency Distr. 300: C6
Plot
N N 4160
mu μ 99.41
sigma σ 1.12
Efficiency Distr. 400: C6
Plot
N N 4160
mu μ 99.15
sigma σ 1.37
Background Map 50: C6
Plot
RealHitrate Real Hitrate 44.82 MHz/cm2
Background Map 100: C6
Plot
RealHitrate Real Hitrate 91.80 MHz/cm2
Background Map 150: C6
Plot
RealHitrate Real Hitrate 140.67 MHz/cm2
Background Map 200: C6
Plot
RealHitrate Real Hitrate 190.02 MHz/cm2
Background Map 250: C6
Plot
RealHitrate Real Hitrate 241.63 MHz/cm2
Background Map 300: C6
Plot
RealHitrate Real Hitrate 291.51 MHz/cm2
Background Map 400: C6
Plot
RealHitrate Real Hitrate 352.99 MHz/cm2
Retrim Hot Pix 150: C6
Retrim Hot Pix 50: C6
Masked Hot Pixels 300: C6
Masked Hot Pixels 100: C6
Hit Map 300: C6
Plot
RealHitrate Real Hitrate 288.59 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C6
Hit Map 100: C6
Plot
RealHitrate Real Hitrate 88.98 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C6
Col. Read. Unif. 300: C6
Plot
N N 8440167
mu μ 179456
sigma σ 27521.11
Col. Read. Unif. 100: C6
Plot
N N 2604397
mu μ 55342
sigma σ 8301.27
Read. Unif. over Time 300: C6
Plot
N N 9331690
mu μ 9464
sigma_th σ_th 97.28
Time unif. distribution 300: C6
Plot
chi2/ndf chi2/ndf 10.40
sigma σ 118.66
sigma_th σ_th 97.30
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C6
Plot
N N 2877781
mu μ 2919
sigma_th σ_th 54.02
Time unif. distribution 100: C6
Plot
chi2/ndf chi2/ndf 1.21
sigma σ 57.30
sigma_th σ_th 54.03
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C6
Col. Uniformity per Event: C6 300
Plot
mu μ 26.74
sigma fit error of μ 2.12
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C6 100
Plot
mu μ 27.25
sigma fit error of μ 2.07
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C6 250
Plot
N N 3944
mu μ 329.75
sigma RMS 122.55
threshold thr 1492.49
fit fit Gaussian
fit_peak μ fit 308.75
fit_sigma σ fit 72.85
MeasuredHitrate Measured hitrate: 74.4
under <= 152.00
over >= 64.00
Alive Map: C6
DC Efficiency Distribution: C6
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.91
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.78
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C6
