Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 8
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 764/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 4969/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.91/99.81
EfficiencyFit Efficiency Fit chi2/ndf: 0.21, # points: 57
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 C/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 C/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C8
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.21
NumberFitPoints # fit points 57
p0 p0 99.92
p1 p1 6.00e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.91
InterpolatedEfficiency120 Interpol. Efficiency 120 99.81
Efficiency Map 50: C8
Efficiency Map 100: C8
Efficiency Map 150: C8
Efficiency Map 200: C8
Efficiency Map 250: C8
Efficiency Map 300: C8
Efficiency Map 400: C8
Efficiency Distr. 50: C8
Plot
N N 4160
mu μ 99.90
sigma σ 1.60
Efficiency Distr. 100: C8
Plot
N N 4160
mu μ 99.81
sigma σ 1.65
Efficiency Distr. 150: C8
Plot
N N 4160
mu μ 99.72
sigma σ 1.70
Efficiency Distr. 200: C8
Plot
N N 4160
mu μ 99.60
sigma σ 1.77
Efficiency Distr. 250: C8
Plot
N N 4160
mu μ 99.50
sigma σ 1.84
Efficiency Distr. 300: C8
Plot
N N 4160
mu μ 99.37
sigma σ 1.91
Efficiency Distr. 400: C8
Plot
N N 4160
mu μ 99.12
sigma σ 2.07
Background Map 50: C8
Plot
RealHitrate Real Hitrate 48.57 MHz/cm2
Background Map 100: C8
Plot
RealHitrate Real Hitrate 99.80 MHz/cm2
Background Map 150: C8
Plot
RealHitrate Real Hitrate 151.46 MHz/cm2
Background Map 200: C8
Plot
RealHitrate Real Hitrate 205.22 MHz/cm2
Background Map 250: C8
Plot
RealHitrate Real Hitrate 259.82 MHz/cm2
Background Map 300: C8
Plot
RealHitrate Real Hitrate 313.21 MHz/cm2
Background Map 400: C8
Plot
RealHitrate Real Hitrate 374.62 MHz/cm2
Retrim Hot Pix 150: C8
Retrim Hot Pix 50: C8
Masked Hot Pixels 300: C8
Masked Hot Pixels 100: C8
Hit Map 300: C8
Plot
RealHitrate Real Hitrate 281.55 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C8
Hit Map 100: C8
Plot
RealHitrate Real Hitrate 96.80 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C8
Col. Read. Unif. 300: C8
Plot
N N 8330719
mu μ 175075
sigma σ 29629.51
Col. Read. Unif. 100: C8
Plot
N N 2865945
mu μ 60206
sigma σ 9636.49
Read. Unif. over Time 300: C8
Plot
N N 9103878
mu μ 9233
sigma_th σ_th 96.09
Time unif. distribution 300: C8
Plot
chi2/ndf chi2/ndf 90.67
sigma σ 3062.11
sigma_th σ_th 96.10
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C8
Plot
N N 3130721
mu μ 3175
sigma_th σ_th 56.35
Time unif. distribution 100: C8
Plot
chi2/ndf chi2/ndf 1.27
sigma σ 58.22
sigma_th σ_th 56.35
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C8
Col. Uniformity per Event: C8 300
Plot
mu μ 27.91
sigma fit error of μ 2.06
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 4969
Col. Uniformity per Event: C8 100
Plot
mu μ 27.56
sigma fit error of μ 2.06
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C8 250
Plot
N N 3954
mu μ 330.86
sigma RMS 116.07
threshold thr 1439.63
fit fit Gaussian
fit_peak μ fit 313.54
fit_sigma σ fit 69.83
MeasuredHitrate Measured hitrate: 74.4
under <= 154.00
over >= 52.00
Alive Map: C8
DC Efficiency Distribution: C8
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.92
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.78
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C8
