Test Date: 2015-07-10 10:45
Analysis date: 2016-05-25 21:06
Analysis date: 2016-05-25 21:06
M2027 XRayHRQualification
Summary
| Module | Module | M2027 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 75 | |
| BumpBondingDefects | Bump Bonding Defects | 75 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.27 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.85 | 99.02 | 0.61 | 76.5 | 4 | 26.0 | 0/0 | 0 | 1925 | 166 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.86 | 99.30 | 0.48 | 82.0 | 1 | 27.7 | 0/0 | 0 | 1952 | 169 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.37 | 0.42 | 73.9 | 0 | 24.6 | 0/0 | 0 | 1909 | 158 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.35 | 0.4 | 123.2 | 0 | 42.6 | 0/0 | 0 | 2053 | 159 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.5 | 127.5 | 0 | 44.3 | 0/0 | 0 | 2073 | 161 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.39 | 0.57 | 165.4 | 0 | 58.3 | 0/0 | 0 | 2152 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.37 | 0.42 | 161.6 | 0 | 55.9 | 0/0 | 0 | 2128 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.41 | 0.62 | 147.0 | 0 | 50.6 | 0/0 | 0 | 2100 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.40 | 0.99 | 142.9 | 0 | 49.3 | 0/0 | 0 | 2126 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.40 | 0.72 | 136.6 | 0 | 47.2 | 0/0 | 0 | 2092 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.35 | 0.47 | 153.1 | 0 | 53.8 | 0/0 | 0 | 2149 | 172 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 99.06 | 0.77 | 123.0 | 0 | 42.5 | 0/0 | 0 | 2089 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.85 | 99.35 | 0.65 | 113.4 | 0 | 39.1 | 0/0 | 0 | 2066 | 160 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.00 | 0.44 | 66.8 | 0 | 22.2 | 0/0 | 0 | 1932 | 150 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.30 | 0.46 | 72.8 | 0 | 24.5 | 0/0 | 0 | 1958 | 155 | 0 |
|
Chip 15
|
B
|
70 | 0 | 99.83 | 98.98 | 0.43 | 72.1 | 70 | 24.4 | 0/0 | 0 | 1937 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-07-10 | |
| TestTime | Test Time | 10:45 | |
| TestDuration | Duration | 1:58:24 | |
| pXar | pXar version | v2.2.5+45~gbf85984 | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 4 | |
| nWarnings | # Warnings | 3 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 3 |
