Test Date: 2015-08-21 17:53
Analysis date: 2016-05-25 21:16
Analysis date: 2016-05-25 21:16
M2028 XRayHRQualification
Summary
| Module | Module | M2028 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 43 | |
| BumpBondingDefects | Bump Bonding Defects | 36 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.29 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.85 | 99.10 | 0.92 | 89.9 | 0 | 30.7 | 0/0 | 0 | 2002 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.31 | 0.71 | 101.2 | 0 | 34.2 | 0/0 | 0 | 2034 | 168 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.83 | 99.05 | 0.62 | 89.2 | 1 | 29.7 | 0/0 | 0 | 2006 | 160 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.89 | 99.32 | 0.56 | 160.3 | 0 | 56.3 | 0/0 | 0 | 2175 | 158 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.31 | 0.57 | 167.8 | 0 | 58.8 | 0/0 | 0 | 2210 | 166 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.36 | 0.56 | 181.4 | 0 | 64.3 | 0/0 | 0 | 2218 | 149 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.18 | 0.96 | 162.5 | 0 | 56.7 | 0/0 | 0 | 2183 | 145 | 0 |
|
Chip 7
|
A
|
31 | 0 | 99.89 | 99.37 | 0.66 | 184.2 | 27 | 64.1 | 0/0 | 0 | 2174 | 151 | 2 |
|
Chip 8
|
A
|
4 | 0 | 99.89 | 99.29 | 0.51 | 164.9 | 4 | 57.2 | 0/0 | 0 | 2171 | 160 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.37 | 0.69 | 163.6 | 0 | 56.8 | 0/0 | 0 | 2179 | 154 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.36 | 0.49 | 187.2 | 0 | 66.8 | 0/0 | 0 | 2236 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.37 | 0.4 | 164.6 | 0 | 57.6 | 0/0 | 0 | 2192 | 167 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.34 | 0.59 | 144.4 | 0 | 50.2 | 0/0 | 0 | 2141 | 161 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.80 | 99.32 | 1.11 | 90.7 | 0 | 30.5 | 0/0 | 0 | 2035 | 161 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.28 | 0.96 | 90.7 | 1 | 30.3 | 0/0 | 0 | 1997 | 162 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.85 | 99.28 | 0.64 | 95.2 | 3 | 32.7 | 0/0 | 0 | 2011 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-21 | |
| TestTime | Test Time | 17:53 | |
| TestDuration | Duration | 1:26:58 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 3 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 3 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
