Test Date: 2015-11-23 13:32
Analysis date: 2016-05-25 21:22
Analysis date: 2016-05-25 21:22
M2029 XRayHRQualification
Summary
| Module | Module | M2029 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 34 | |
| BumpBondingDefects | Bump Bonding Defects | 34 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.26 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
10 | 0 | 99.88 | 99.31 | 0.59 | 88.1 | 10 | 29.9 | 0/0 | 0 | 1976 | 163 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 98.99 | 0.56 | 91.1 | 0 | 30.4 | 0/0 | 0 | 1991 | 166 | 0 |
|
Chip 2
|
A
|
5 | 0 | 99.84 | 99.06 | 0.69 | 92.3 | 5 | 30.8 | 0/0 | 0 | 1974 | 172 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.5 | 156.7 | 0 | 55.2 | 0/0 | 0 | 2139 | 168 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.31 | 1.09 | 172.5 | 0 | 59.8 | 0/0 | 0 | 2174 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.36 | 0.51 | 202.4 | 0 | 71.7 | 0/0 | 0 | 2215 | 167 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.57 | 186.0 | 0 | 65.5 | 0/0 | 0 | 2180 | 160 | 0 |
|
Chip 7
|
A
|
9 | 0 | 99.86 | 99.34 | 0.58 | 190.3 | 9 | 67.0 | 0/0 | 0 | 2185 | 158 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.37 | 0.46 | 193.6 | 0 | 68.0 | 0/0 | 0 | 2208 | 157 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.37 | 0.62 | 192.6 | 0 | 67.2 | 0/0 | 0 | 2184 | 163 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.77 | 180.4 | 0 | 63.5 | 0/0 | 0 | 2156 | 155 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.87 | 99.31 | 0.72 | 155.0 | 2 | 53.5 | 0/0 | 0 | 2153 | 160 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.89 | 99.30 | 0.59 | 151.3 | 1 | 52.4 | 0/0 | 0 | 2120 | 160 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.24 | 0.41 | 85.9 | 0 | 28.4 | 0/0 | 0 | 1979 | 157 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.22 | 0.92 | 93.4 | 1 | 31.1 | 0/0 | 0 | 1968 | 172 | 0 |
|
Chip 15
|
A
|
6 | 0 | 99.84 | 99.00 | 0.81 | 87.2 | 6 | 29.2 | 0/0 | 0 | 1992 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-11-23 | |
| TestTime | Test Time | 13:32 | |
| TestDuration | Duration | 1:33:19 | |
| pXar | pXar version | v2.6.0+26~g89693ff | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 25 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 2 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_readback_count | Readback start marker | 2 |
