Test Date: 2015-07-24 15:32
Analysis date: 2016-05-25 22:41
Analysis date: 2016-05-25 22:41
M2042 XRayHRQualification
Summary
| Module | Module | M2042 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.28 | % |
| Noise | Mean Noise | 158 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.86 | 99.31 | 0.49 | 79.7 | 1 | 26.7 | 0/0 | 0 | 2004 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 98.94 | 1.26 | 93.8 | 0 | 31.5 | 0/0 | 0 | 2022 | 161 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.86 | 99.36 | 0.47 | 85.8 | 0 | 28.7 | 0/0 | 0 | 2002 | 158 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.37 | 0.43 | 157.1 | 0 | 55.4 | 0/0 | 0 | 2226 | 166 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.30 | 1.31 | 155.2 | 0 | 54.4 | 0/0 | 0 | 2183 | 160 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.34 | 0.81 | 200.5 | 0 | 71.6 | 0/0 | 0 | 2268 | 163 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.30 | 0.57 | 188.4 | 0 | 66.3 | 0/0 | 0 | 2248 | 151 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.37 | 0.53 | 204.7 | 0 | 71.5 | 0/0 | 0 | 2293 | 171 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.40 | 0.58 | 189.8 | 0 | 66.6 | 0/0 | 0 | 2248 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.89 | 99.36 | 0.29 | 169.3 | 0 | 58.8 | 0/0 | 0 | 2186 | 151 | 0 |
|
Chip 10
|
A
|
3 | 0 | 99.87 | 99.30 | 0.5 | 177.8 | 2 | 62.4 | 0/0 | 0 | 2208 | 152 | 1 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.30 | 0.91 | 156.1 | 0 | 53.8 | 0/0 | 0 | 2176 | 153 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.33 | 0.8 | 146.4 | 0 | 50.8 | 0/0 | 0 | 2164 | 158 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.32 | 0.69 | 84.9 | 0 | 28.1 | 0/0 | 0 | 2019 | 157 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.13 | 0.99 | 88.0 | 0 | 29.2 | 0/0 | 0 | 2026 | 161 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.83 | 98.98 | 0.95 | 86.4 | 1 | 29.0 | 0/0 | 0 | 2018 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-07-24 | |
| TestTime | Test Time | 15:32 | |
| TestDuration | Duration | 1:24:19 | |
| pXar | pXar version | v2.2.5+46~gdbe75a1 | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 2 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
