Test Date: 2015-08-11 16:58
Analysis date: 2016-05-25 23:17
Analysis date: 2016-05-25 23:17
M2048 XRayHRQualification
Summary
| Module | Module | M2048 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 156 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.87 | 99.26 | 0.67 | 88.8 | 1 | 30.1 | 0/0 | 0 | 2028 | 168 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.87 | 99.28 | 0.84 | 97.1 | 0 | 32.6 | 0/0 | 0 | 1994 | 170 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.97 | 0.6 | 81.0 | 0 | 26.6 | 0/0 | 0 | 1955 | 152 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.87 | 99.37 | 0.54 | 144.4 | 0 | 50.4 | 0/0 | 0 | 2154 | 155 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.32 | 0.64 | 165.2 | 0 | 57.7 | 0/0 | 0 | 2198 | 162 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.39 | 0.92 | 197.6 | 0 | 70.0 | 0/0 | 0 | 2270 | 161 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.90 | 99.36 | 0.75 | 158.2 | 1 | 54.0 | 0/0 | 0 | 2168 | 152 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.37 | 0.53 | 173.1 | 0 | 59.8 | 0/0 | 0 | 2211 | 142 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.37 | 0.75 | 192.8 | 0 | 67.2 | 0/0 | 0 | 2265 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.33 | 0.41 | 192.3 | 0 | 67.9 | 0/0 | 0 | 2260 | 150 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.39 | 196.8 | 0 | 70.1 | 0/0 | 0 | 2266 | 156 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.34 | 0.48 | 162.4 | 0 | 56.6 | 0/0 | 0 | 2207 | 149 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.89 | 99.30 | 0.69 | 152.0 | 1 | 52.9 | 0/0 | 0 | 2169 | 145 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.29 | 0.42 | 97.9 | 0 | 32.8 | 0/0 | 0 | 2079 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.21 | 1.13 | 89.7 | 0 | 29.9 | 0/0 | 0 | 2047 | 149 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.27 | 0.73 | 97.7 | 0 | 33.7 | 0/0 | 0 | 2077 | 166 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 16:58 | |
| TestDuration | Duration | 1:26:55 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 4 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 5 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
