Test Date: 2015-08-12 14:10
Analysis date: 2016-05-25 23:35
Analysis date: 2016-05-25 23:35
M2051 XRayHRQualification
Summary
| Module | Module | M2051 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.31 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.86 | 99.32 | 0.75 | 90.0 | 2 | 30.7 | 0/0 | 0 | 2034 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.08 | 0.83 | 100.6 | 0 | 34.1 | 0/0 | 0 | 2064 | 162 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.27 | 0.47 | 91.4 | 0 | 30.6 | 0/0 | 0 | 2032 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.90 | 99.39 | 0.55 | 173.2 | 0 | 60.4 | 0/0 | 0 | 2232 | 176 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.32 | 0.66 | 170.4 | 0 | 59.9 | 0/0 | 0 | 2209 | 157 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.37 | 0.51 | 202.2 | 0 | 72.3 | 0/0 | 0 | 2290 | 159 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.61 | 174.0 | 0 | 60.8 | 0/0 | 0 | 2213 | 155 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.88 | 99.33 | 0.69 | 195.0 | 2 | 68.4 | 0/0 | 0 | 2252 | 156 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.90 | 99.38 | 0.37 | 173.0 | 0 | 60.9 | 0/0 | 0 | 2234 | 151 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.34 | 0.58 | 190.2 | 0 | 66.9 | 0/0 | 0 | 2271 | 158 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.33 | 0.76 | 194.6 | 0 | 70.2 | 0/0 | 0 | 2316 | 162 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.31 | 0.3 | 159.1 | 0 | 55.6 | 0/0 | 0 | 2202 | 160 | 1 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.37 | 0.38 | 133.9 | 0 | 45.9 | 0/0 | 0 | 2129 | 155 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.26 | 0.45 | 91.8 | 0 | 30.8 | 0/0 | 0 | 2055 | 164 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.30 | 0.56 | 94.9 | 0 | 32.1 | 0/0 | 0 | 2033 | 168 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.26 | 0.59 | 95.5 | 0 | 32.8 | 0/0 | 0 | 2050 | 167 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-12 | |
| TestTime | Test Time | 14:10 | |
| TestDuration | Duration | 1:27:24 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 5 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 6 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 1 |
