Test Date: 2015-08-11 12:52
Analysis date: 2016-05-26 00:41
Analysis date: 2016-05-26 00:41
M2063 XRayHRQualification
Summary
| Module | Module | M2063 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.25 | 0.71 | 85.3 | 0 | 28.9 | 0/0 | 0 | 1964 | 160 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.31 | 0.8 | 96.3 | 0 | 32.5 | 0/0 | 0 | 2008 | 166 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.29 | 0.48 | 86.1 | 0 | 28.6 | 0/0 | 0 | 1963 | 172 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.87 | 99.38 | 0.59 | 158.2 | 0 | 55.2 | 0/0 | 0 | 2196 | 163 | 1 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.29 | 0.42 | 173.7 | 0 | 60.2 | 0/0 | 0 | 2189 | 167 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.35 | 0.69 | 202.7 | 0 | 71.5 | 0/0 | 0 | 2269 | 167 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.38 | 0.82 | 197.8 | 0 | 69.0 | 0/0 | 0 | 2239 | 179 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.35 | 0.7 | 207.6 | 0 | 72.6 | 0/0 | 0 | 2254 | 163 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.33 | 0.41 | 214.6 | 0 | 74.8 | 0/0 | 0 | 2284 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.19 | 1.0 | 164.7 | 0 | 56.9 | 0/0 | 0 | 2174 | 154 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.26 | 1.15 | 193.4 | 0 | 68.8 | 0/0 | 0 | 2228 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.85 | 99.31 | 0.65 | 170.4 | 0 | 59.1 | 0/0 | 0 | 2160 | 155 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.37 | 0.67 | 147.6 | 0 | 51.2 | 0/0 | 0 | 2136 | 160 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.87 | 99.34 | 0.39 | 93.0 | 0 | 31.1 | 0/0 | 0 | 1975 | 165 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.32 | 0.73 | 92.8 | 0 | 31.1 | 0/0 | 0 | 2006 | 161 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.26 | 0.99 | 93.2 | 0 | 31.6 | 0/0 | 0 | 2014 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-11 | |
| TestTime | Test Time | 12:52 | |
| TestDuration | Duration | 1:26:46 | |
| pXar | pXar version | v2.2.5+88~g694c14c | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 2 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 2 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
