Test Date: 2015-09-11 16:58
Analysis date: 2016-05-26 02:11
Analysis date: 2016-05-26 02:11
M2078 XRayHRQualification
Summary
| Module | Module | M2078 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 17 | |
| BumpBondingDefects | Bump Bonding Defects | 7 | |
| NoisyPixels | Noisy Pixels | 7 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.20 | % |
| Noise | Mean Noise | 169 | e- |
| SpecialDefects | Defects | XrayDoubleColumnDefects |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.80 | 98.86 | 0.63 | 71.9 | 3 | 24.1 | 0/0 | 0 | 1921 | 185 | 0 |
|
Chip 1
|
A
|
3 | 0 | 99.85 | 99.01 | 0.66 | 74.0 | 1 | 24.7 | 0/0 | 0 | 1928 | 178 | 1 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 98.99 | 0.54 | 57.2 | 0 | 18.6 | 0/0 | 0 | 1901 | 151 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.86 | 99.25 | 0.68 | 115.2 | 0 | 39.4 | 0/0 | 0 | 2048 | 174 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.23 | 0.84 | 120.6 | 0 | 41.2 | 0/0 | 0 | 2063 | 165 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.37 | 0.56 | 135.2 | 0 | 47.3 | 0/0 | 0 | 2114 | 162 | 0 |
|
Chip 6
|
A
|
3 | 0 | 99.88 | 99.35 | 0.73 | 123.5 | 0 | 42.5 | 0/0 | 0 | 1990 | 159 | 3 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.36 | 0.42 | 128.4 | 0 | 43.8 | 0/0 | 0 | 2056 | 169 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.35 | 0.45 | 133.0 | 0 | 45.4 | 0/0 | 0 | 2068 | 161 | 0 |
|
Chip 9
|
A
|
2 | 0 | 99.87 | 99.33 | 0.55 | 147.7 | 0 | 50.9 | 0/0 | 0 | 2078 | 168 | 1 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.08 | 0.87 | 160.0 | 0 | 56.0 | 0/0 | 0 | 2169 | 173 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.36 | 1.01 | 128.4 | 0 | 44.2 | 0/0 | 0 | 2092 | 167 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.87 | 99.35 | 0.58 | 122.7 | 0 | 42.1 | 0/0 | 0 | 1969 | 172 | 2 |
|
Chip 13
|
A
|
1 | 0 | 99.83 | 99.05 | 0.6 | 71.2 | 1 | 23.6 | 0/0 | 0 | 1914 | 166 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.03 | 0.69 | 80.2 | 0 | 26.9 | 0/0 | 0 | 1944 | 174 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.87 | 99.20 | 0.56 | 80.6 | 2 | 27.6 | 0/0 | 0 | 1926 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-11 | |
| TestTime | Test Time | 16:58 | |
| TestDuration | Duration | 1:26:36 | |
| pXar | pXar version | prod-10+24~g09f6d2c | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
