Test Date: 2015-08-24 17:49
Analysis date: 2016-05-26 02:32
Analysis date: 2016-05-26 02:32
M2082 XRayHRQualification
Summary
| Module | Module | M2082 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.36 | 0.59 | 90.1 | 0 | 30.7 | 0/0 | 0 | 2038 | 165 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.84 | 99.08 | 0.73 | 92.3 | 0 | 31.0 | 0/0 | 0 | 1993 | 161 | 1 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.30 | 0.41 | 81.1 | 0 | 26.7 | 0/0 | 0 | 2009 | 156 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.39 | 0.48 | 160.5 | 0 | 56.5 | 0/0 | 0 | 2216 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.40 | 0.32 | 145.9 | 0 | 50.7 | 0/0 | 0 | 2152 | 153 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.89 | 99.39 | 0.55 | 181.4 | 0 | 64.1 | 0/0 | 0 | 2206 | 158 | 1 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.38 | 0.79 | 184.4 | 0 | 65.4 | 0/0 | 0 | 2262 | 156 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.36 | 0.56 | 188.0 | 0 | 66.5 | 0/0 | 0 | 2271 | 155 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.30 | 0.83 | 174.8 | 0 | 60.6 | 0/0 | 0 | 2235 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.77 | 166.2 | 0 | 57.9 | 0/0 | 0 | 2223 | 147 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.35 | 0.6 | 195.4 | 0 | 70.0 | 0/0 | 0 | 2308 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.89 | 99.37 | 0.38 | 159.1 | 0 | 55.4 | 0/0 | 0 | 2205 | 159 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.33 | 0.44 | 171.4 | 0 | 59.8 | 0/0 | 0 | 2237 | 169 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.05 | 1.0 | 98.9 | 0 | 33.3 | 0/0 | 0 | 2092 | 164 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.22 | 0.92 | 101.1 | 0 | 34.2 | 0/0 | 0 | 2083 | 161 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.31 | 0.81 | 95.2 | 0 | 32.5 | 0/0 | 0 | 2066 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-24 | |
| TestTime | Test Time | 17:49 | |
| TestDuration | Duration | 0:29:22 | |
| pXar | pXar version | prod-01+86~g1838649 | |
| DTB_FW | DTB FW | 4.0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 6 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 6 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_tokenchain_count | Token Chain Length | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
