Test Date: 2015-08-28 10:32
Analysis date: 2016-05-26 02:51
Analysis date: 2016-05-26 02:51
M2085 XRayHRQualification
Summary
| Module | Module | M2085 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 23 | |
| BumpBondingDefects | Bump Bonding Defects | 13 | |
| NoisyPixels | Noisy Pixels | 4 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.26 | % |
| Noise | Mean Noise | 158 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.22 | 0.64 | 81.0 | 0 | 26.8 | 0/0 | 0 | 1977 | 151 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.87 | 99.24 | 0.58 | 91.6 | 0 | 30.5 | 0/0 | 0 | 2024 | 159 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.81 | 99.13 | 2.62 | 83.3 | 0 | 27.3 | 0/0 | 0 | 1981 | 149 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.86 | 99.28 | 2.03 | 142.7 | 0 | 50.0 | 0/0 | 0 | 2072 | 160 | 1 |
|
Chip 4
|
A
|
2 | 0 | 99.85 | 99.31 | 0.63 | 182.2 | 0 | 62.9 | 0/0 | 0 | 2142 | 172 | 2 |
|
Chip 5
|
A
|
3 | 0 | 99.82 | 99.18 | 58.79 | 215.2 | 0 | 75.7 | 0/0 | 0 | 2298 | 170 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.32 | 0.95 | 205.6 | 0 | 71.8 | 0/0 | 0 | 2272 | 161 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.38 | 0.57 | 208.8 | 0 | 73.5 | 0/0 | 0 | 2306 | 171 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.33 | 0.57 | 194.9 | 0 | 68.8 | 0/0 | 0 | 2240 | 153 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.37 | 0.83 | 186.6 | 0 | 65.8 | 0/0 | 0 | 2241 | 158 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.36 | 0.67 | 188.4 | 0 | 67.2 | 0/0 | 0 | 2231 | 149 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.37 | 0.46 | 145.4 | 0 | 50.5 | 0/0 | 0 | 2117 | 148 | 1 |
|
Chip 12
|
A
|
1 | 0 | 99.87 | 99.40 | 0.66 | 152.7 | 1 | 53.0 | 0/0 | 0 | 2163 | 159 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.85 | 99.29 | 0.4 | 90.5 | 2 | 30.0 | 0/0 | 0 | 2029 | 161 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 99.03 | 0.99 | 81.8 | 0 | 26.8 | 0/0 | 0 | 1993 | 154 | 0 |
|
Chip 15
|
A
|
10 | 0 | 99.84 | 98.99 | 0.87 | 80.7 | 10 | 26.8 | 0/0 | 0 | 1998 | 157 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-28 | |
| TestTime | Test Time | 10:32 | |
| TestDuration | Duration | 1:35:13 | |
| pXar | pXar version | v2.5+57~g44d0777 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
