Test Date: 2015-08-28 10:32
Analysis date: 2016-05-26 03:00
Analysis date: 2016-05-26 03:00
M2086 XRayHRQualification
Summary
| Module | Module | M2086 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 45 | |
| BumpBondingDefects | Bump Bonding Defects | 37 | |
| NoisyPixels | Noisy Pixels | 5 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.30 | % |
| Noise | Mean Noise | 158 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
14 | 0 | 99.82 | 99.25 | 6.22 | 92.7 | 10 | 31.4 | 0/0 | 0 | 1941 | 164 | 2 |
|
Chip 1
|
A
|
1 | 0 | 99.84 | 99.32 | 1.25 | 102.3 | 0 | 34.2 | 0/0 | 0 | 2026 | 175 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.86 | 99.31 | 0.5 | 92.5 | 1 | 30.9 | 0/0 | 0 | 2025 | 173 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.89 | 99.36 | 0.41 | 149.7 | 0 | 52.5 | 0/0 | 0 | 2203 | 155 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.76 | 146.9 | 0 | 50.8 | 0/0 | 0 | 2142 | 156 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.35 | 0.67 | 182.5 | 0 | 65.0 | 0/0 | 0 | 2257 | 153 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.29 | 0.48 | 188.2 | 0 | 65.6 | 0/0 | 0 | 2224 | 156 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.36 | 0.49 | 175.4 | 0 | 61.2 | 0/0 | 0 | 2201 | 147 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.87 | 99.32 | 0.68 | 175.1 | 0 | 60.9 | 0/0 | 0 | 2162 | 155 | 3 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.34 | 0.79 | 181.3 | 0 | 63.0 | 0/0 | 0 | 2214 | 149 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.35 | 0.54 | 192.4 | 0 | 68.4 | 0/0 | 0 | 2243 | 149 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.36 | 0.45 | 161.2 | 0 | 55.9 | 0/0 | 0 | 2177 | 150 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.32 | 0.65 | 142.5 | 0 | 49.0 | 0/0 | 0 | 2127 | 150 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.85 | 99.20 | 0.53 | 89.2 | 1 | 29.7 | 0/0 | 0 | 2031 | 158 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.06 | 0.97 | 95.0 | 0 | 31.7 | 0/0 | 0 | 2032 | 159 | 0 |
|
Chip 15
|
A
|
25 | 0 | 99.86 | 99.27 | 0.66 | 100.4 | 25 | 33.9 | 0/0 | 0 | 2037 | 173 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-08-28 | |
| TestTime | Test Time | 10:32 | |
| TestDuration | Duration | 1:35:13 | |
| pXar | pXar version | v2.5+57~g44d0777 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
