Test Date: 2015-09-04 17:08
Analysis date: 2016-05-26 03:09
Analysis date: 2016-05-26 03:09
M2088 XRayHRQualification
Summary
| Module | Module | M2088 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 91 | |
| BumpBondingDefects | Bump Bonding Defects | 89 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.24 | % |
| Noise | Mean Noise | 157 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.86 | 99.09 | 0.41 | 72.6 | 2 | 24.7 | 0/0 | 0 | 1949 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.17 | 0.57 | 79.4 | 0 | 26.9 | 0/0 | 0 | 1970 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.44 | 0.51 | 70.2 | 0 | 23.4 | 0/0 | 0 | 1958 | 153 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.84 | 99.05 | 0.95 | 118.5 | 0 | 41.1 | 0/0 | 0 | 2078 | 155 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.37 | 0.44 | 131.9 | 0 | 46.0 | 0/0 | 0 | 2116 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.38 | 0.41 | 169.7 | 0 | 60.6 | 0/0 | 0 | 2190 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.40 | 0.67 | 145.9 | 0 | 50.9 | 0/0 | 0 | 2137 | 152 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.29 | 0.65 | 154.6 | 0 | 54.2 | 0/0 | 0 | 2159 | 146 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.28 | 0.82 | 158.6 | 0 | 55.6 | 0/0 | 0 | 2191 | 156 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.33 | 1.01 | 156.9 | 1 | 55.1 | 0/0 | 0 | 2173 | 162 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.38 | 0.58 | 157.8 | 0 | 56.4 | 0/0 | 0 | 2189 | 161 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.13 | 0.95 | 132.7 | 0 | 46.3 | 0/0 | 0 | 2112 | 158 | 0 |
|
Chip 12
|
A
|
1 | 0 | 99.86 | 99.30 | 0.57 | 129.0 | 1 | 44.6 | 0/0 | 0 | 2097 | 171 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.85 | 99.28 | 0.51 | 67.2 | 2 | 22.5 | 0/0 | 0 | 1962 | 157 | 0 |
|
Chip 14
|
B
|
71 | 0 | 99.85 | 98.98 | 0.52 | 65.3 | 69 | 21.8 | 0/0 | 0 | 1676 | 155 | 2 |
|
Chip 15
|
A
|
14 | 0 | 99.84 | 98.92 | 0.52 | 64.8 | 14 | 21.9 | 0/0 | 0 | 1966 | 157 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-04 | |
| TestTime | Test Time | 17:08 | |
| TestDuration | Duration | 1:18:56 | |
| pXar | pXar version | prod-10 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
