Test Date: 2015-09-10 11:57
Analysis date: 2016-05-26 04:01
Analysis date: 2016-05-26 04:01
M2097 XRayHRQualification
Summary
| Module | Module | M2097 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.25 | % |
| Noise | Mean Noise | 164 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.81 | 98.91 | 1.07 | 66.1 | 0 | 22.2 | 0/0 | 0 | 1954 | 157 | 1 |
|
Chip 1
|
A
|
3 | 0 | 99.84 | 98.98 | 0.97 | 77.1 | 0 | 25.8 | 0/0 | 0 | 1953 | 181 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.39 | 0.42 | 66.9 | 0 | 22.6 | 0/0 | 0 | 1962 | 161 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.37 | 0.55 | 117.0 | 0 | 40.5 | 0/0 | 0 | 2081 | 172 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.86 | 99.13 | 1.05 | 122.0 | 0 | 42.0 | 0/0 | 0 | 2025 | 166 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.39 | 0.36 | 155.2 | 0 | 54.7 | 0/0 | 0 | 2184 | 168 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.35 | 0.66 | 137.3 | 0 | 47.9 | 0/0 | 0 | 2129 | 163 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.89 | 99.35 | 0.46 | 139.6 | 1 | 48.4 | 0/0 | 0 | 2130 | 172 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.29 | 0.93 | 149.8 | 0 | 52.6 | 0/0 | 0 | 2169 | 161 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.85 | 99.34 | 0.51 | 152.9 | 0 | 53.7 | 0/0 | 0 | 2147 | 162 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.28 | 0.34 | 171.1 | 0 | 60.7 | 0/0 | 0 | 2206 | 159 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.33 | 0.5 | 129.0 | 0 | 45.1 | 0/0 | 0 | 2072 | 156 | 1 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.36 | 0.78 | 130.5 | 0 | 45.5 | 0/0 | 0 | 2127 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.26 | 0.58 | 73.5 | 0 | 24.8 | 0/0 | 0 | 1978 | 158 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.23 | 1.1 | 84.1 | 0 | 28.5 | 0/0 | 0 | 2002 | 168 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.86 | 99.04 | 0.49 | 74.3 | 0 | 25.4 | 0/0 | 0 | 1986 | 155 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-10 | |
| TestTime | Test Time | 11:57 | |
| TestDuration | Duration | 0:19:26 | |
| pXar | pXar version | prod-10+24~g09f6d2c | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 16 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 2 | |
| channel_3_count | Channel 3 | 0 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
