Test Date: 2015-09-04 17:08
Analysis date: 2016-05-26 04:21
Analysis date: 2016-05-26 04:21
M2101 XRayHRQualification
Summary
| Module | Module | M2101 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 39 | |
| BumpBondingDefects | Bump Bonding Defects | 36 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.27 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.29 | 0.66 | 95.1 | 0 | 32.7 | 0/0 | 0 | 1994 | 167 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.88 | 99.32 | 0.41 | 95.9 | 0 | 32.5 | 0/0 | 0 | 2005 | 163 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.11 | 0.66 | 84.5 | 0 | 28.5 | 0/0 | 0 | 1981 | 158 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.88 | 99.12 | 0.86 | 144.7 | 0 | 50.8 | 0/0 | 0 | 1941 | 163 | 2 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.67 | 159.6 | 0 | 56.0 | 0/0 | 0 | 2157 | 159 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.33 | 0.99 | 182.4 | 0 | 65.3 | 0/0 | 0 | 2204 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.67 | 187.7 | 0 | 65.5 | 0/0 | 0 | 2231 | 162 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.38 | 0.86 | 197.4 | 0 | 68.6 | 0/0 | 0 | 2251 | 166 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.40 | 0.49 | 169.7 | 0 | 59.1 | 0/0 | 0 | 2180 | 157 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.87 | 99.33 | 0.62 | 184.6 | 1 | 64.2 | 0/0 | 0 | 2194 | 166 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.32 | 0.94 | 176.7 | 0 | 62.5 | 0/0 | 0 | 2183 | 151 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.84 | 99.30 | 0.67 | 172.2 | 0 | 59.4 | 0/0 | 0 | 2197 | 167 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.37 | 0.41 | 144.9 | 0 | 50.0 | 0/0 | 0 | 2107 | 162 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.84 | 99.17 | 0.59 | 84.2 | 1 | 28.0 | 0/0 | 0 | 1984 | 151 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.81 | 98.98 | 0.99 | 99.7 | 1 | 33.8 | 0/0 | 0 | 2029 | 173 | 0 |
|
Chip 15
|
A
|
34 | 0 | 99.88 | 99.27 | 0.6 | 83.3 | 33 | 28.1 | 0/0 | 0 | 1932 | 156 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-04 | |
| TestTime | Test Time | 17:08 | |
| TestDuration | Duration | 1:18:56 | |
| pXar | pXar version | prod-10 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 1 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
