Test Date: 2015-09-10 11:57
Analysis date: 2016-05-26 04:48
Analysis date: 2016-05-26 04:48
M2106 XRayHRQualification
Summary
| Module | Module | M2106 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 46 | |
| BumpBondingDefects | Bump Bonding Defects | 45 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.26 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.83 | 99.05 | 0.91 | 95.6 | 5 | 32.9 | 0/0 | 0 | 2025 | 176 | 0 |
|
Chip 1
|
A
|
6 | 0 | 99.86 | 99.26 | 0.5 | 93.2 | 6 | 31.6 | 0/0 | 0 | 2009 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.31 | 0.35 | 80.5 | 0 | 26.7 | 0/0 | 0 | 1970 | 156 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.34 | 0.43 | 145.9 | 0 | 51.1 | 0/0 | 0 | 2130 | 159 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.87 | 99.28 | 0.88 | 170.3 | 1 | 59.4 | 0/0 | 0 | 2189 | 167 | 0 |
|
Chip 5
|
A
|
3 | 0 | 99.90 | 99.33 | 0.61 | 168.8 | 3 | 59.7 | 0/0 | 0 | 2199 | 155 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.34 | 0.37 | 175.0 | 0 | 61.3 | 0/0 | 0 | 2197 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.34 | 0.73 | 191.6 | 0 | 67.0 | 0/0 | 0 | 2233 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.33 | 0.69 | 178.0 | 0 | 63.0 | 0/0 | 0 | 2221 | 156 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.35 | 0.65 | 188.5 | 0 | 66.5 | 0/0 | 0 | 2232 | 157 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.84 | 99.31 | 1.06 | 198.7 | 1 | 71.0 | 0/0 | 0 | 2269 | 156 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.91 | 99.35 | 0.48 | 158.8 | 0 | 55.8 | 0/0 | 0 | 2147 | 154 | 1 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.20 | 0.56 | 144.9 | 0 | 50.7 | 0/0 | 0 | 2147 | 154 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.84 | 99.04 | 0.72 | 89.3 | 1 | 30.0 | 0/0 | 0 | 2024 | 154 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.06 | 0.77 | 98.7 | 0 | 34.0 | 0/0 | 0 | 2035 | 161 | 0 |
|
Chip 15
|
A
|
28 | 0 | 99.86 | 99.29 | 1.07 | 99.9 | 28 | 34.9 | 0/0 | 0 | 2038 | 162 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-10 | |
| TestTime | Test Time | 11:57 | |
| TestDuration | Duration | 0:19:26 | |
| pXar | pXar version | prod-10+24~g09f6d2c | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
