Test Date: 2015-09-17 11:03
Analysis date: 2016-05-26 06:12
Analysis date: 2016-05-26 06:12
M2115 XRayHRQualification
Summary
| Module | Module | M2115 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 6 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.28 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
5 | 0 | 99.86 | 99.27 | 0.81 | 96.6 | 4 | 32.6 | 0/0 | 0 | 2013 | 181 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.79 | 99.13 | 2.38 | 96.8 | 0 | 32.4 | 0/0 | 0 | 2017 | 172 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.35 | 0.52 | 85.9 | 0 | 28.4 | 0/0 | 0 | 1993 | 168 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.31 | 0.56 | 154.3 | 0 | 53.9 | 0/0 | 0 | 2169 | 162 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.36 | 0.66 | 159.2 | 0 | 55.1 | 0/0 | 0 | 2164 | 164 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.31 | 0.74 | 187.9 | 0 | 66.6 | 0/0 | 0 | 2224 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.36 | 0.55 | 184.8 | 0 | 64.5 | 0/0 | 0 | 2216 | 162 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.39 | 0.55 | 199.6 | 0 | 70.3 | 0/0 | 0 | 2259 | 171 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.36 | 0.59 | 204.6 | 0 | 71.6 | 0/0 | 0 | 2277 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.35 | 0.56 | 181.8 | 0 | 63.4 | 0/0 | 0 | 2211 | 157 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.85 | 99.26 | 1.52 | 193.7 | 0 | 68.3 | 0/0 | 0 | 2218 | 163 | 1 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.32 | 0.44 | 160.7 | 0 | 55.8 | 0/0 | 0 | 2173 | 160 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.38 | 0.39 | 153.5 | 0 | 53.2 | 0/0 | 0 | 2170 | 159 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.31 | 0.41 | 89.4 | 0 | 29.5 | 0/0 | 0 | 2020 | 168 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.04 | 0.79 | 96.2 | 0 | 31.9 | 0/0 | 0 | 2016 | 172 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.01 | 0.99 | 94.0 | 0 | 31.6 | 0/0 | 0 | 2029 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-17 | |
| TestTime | Test Time | 11:03 | |
| TestDuration | Duration | 1:13:7 | |
| pXar | pXar version | prod-10+28~ga8f1456 | |
| DTB_FW | DTB FW | 4.4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 21 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 4 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 1 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 3 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
