Test Date: 2015-12-08 13:49
Analysis date: 2016-05-26 06:54
Analysis date: 2016-05-26 06:54
M2123 XRayHRQualification
Summary
| Module | Module | M2123 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 170 | |
| BumpBondingDefects | Bump Bonding Defects | 169 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.25 | % |
| Noise | Mean Noise | 154 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.00 | 0.56 | 92.0 | 0 | 31.6 | 0/0 | 0 | 2007 | 164 | 0 |
|
Chip 1
|
A
|
23 | 0 | 99.86 | 99.30 | 0.59 | 93.3 | 23 | 31.5 | 0/0 | 0 | 2020 | 158 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.85 | 99.17 | 0.45 | 88.0 | 0 | 29.5 | 0/0 | 0 | 2000 | 160 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.86 | 99.34 | 0.71 | 139.5 | 0 | 48.5 | 0/0 | 0 | 2088 | 147 | 1 |
|
Chip 4
|
A
|
0 | 0 | 99.88 | 99.36 | 0.79 | 146.3 | 0 | 50.7 | 0/0 | 0 | 2130 | 158 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.37 | 0.55 | 166.4 | 0 | 58.5 | 0/0 | 0 | 2181 | 156 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.88 | 99.33 | 0.7 | 158.8 | 1 | 55.0 | 0/0 | 0 | 2132 | 150 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.38 | 0.58 | 164.8 | 0 | 56.8 | 0/0 | 0 | 2188 | 149 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.29 | 0.68 | 175.5 | 0 | 61.0 | 0/0 | 0 | 2167 | 149 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.35 | 0.48 | 160.4 | 0 | 55.5 | 0/0 | 0 | 2154 | 143 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.38 | 0.49 | 167.1 | 1 | 58.3 | 0/0 | 0 | 2154 | 145 | 0 |
|
Chip 11
|
A
|
20 | 0 | 99.86 | 99.33 | 0.66 | 156.8 | 20 | 54.2 | 0/0 | 0 | 2174 | 153 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.84 | 99.16 | 0.84 | 140.1 | 0 | 48.1 | 0/0 | 0 | 2104 | 151 | 0 |
|
Chip 13
|
B
|
116 | 0 | 99.83 | 99.01 | 0.62 | 80.3 | 116 | 26.5 | 0/0 | 0 | 1968 | 151 | 0 |
|
Chip 14
|
A
|
2 | 0 | 99.83 | 99.01 | 0.69 | 91.3 | 2 | 30.4 | 0/0 | 0 | 2025 | 162 | 0 |
|
Chip 15
|
A
|
6 | 0 | 99.86 | 99.22 | 0.63 | 95.5 | 6 | 32.7 | 0/0 | 0 | 2020 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-12-08 | |
| TestTime | Test Time | 13:49 | |
| TestDuration | Duration | 1:40:25 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
