Test Date: 2016-01-18 14:11
Analysis date: 2016-05-26 07:37
Analysis date: 2016-05-26 07:37
M2130 XRayHRQualification
Summary
| Module | Module | M2130 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 63 | |
| BumpBondingDefects | Bump Bonding Defects | 51 | |
| NoisyPixels | Noisy Pixels | 9 | |
| HotPixelDefects | Hot Pixels | 10 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.28 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
58 | 0 | 99.84 | 99.01 | 0.58 | 33.1 | 97.8 | 47 | 0/0 | 0 | 1729 | 176 | 9 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.24 | 0.56 | 33.9 | 100.1 | 0 | 0/0 | 0 | 2039 | 169 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.85 | 99.23 | 1.31 | 31.9 | 95.7 | 1 | 0/0 | 0 | 2003 | 188 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.35 | 0.73 | 59.8 | 171.1 | 0 | 0/0 | 0 | 2214 | 167 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.33 | 0.7 | 58.7 | 165.8 | 0 | 0/0 | 0 | 2188 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.37 | 0.56 | 72.6 | 201.7 | 0 | 0/0 | 0 | 2260 | 165 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.37 | 0.81 | 67.3 | 189.4 | 0 | 0/0 | 0 | 2236 | 155 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.39 | 0.7 | 74.7 | 209.3 | 1 | 0/0 | 0 | 2274 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.36 | 0.66 | 73.1 | 205.7 | 0 | 0/0 | 0 | 2294 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.83 | 99.31 | 0.6 | 74.5 | 209.6 | 0 | 0/0 | 0 | 2293 | 165 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.32 | 0.43 | 76.7 | 214.8 | 0 | 0/0 | 0 | 2296 | 165 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.85 | 99.36 | 0.59 | 61.0 | 173.4 | 0 | 0/0 | 0 | 2221 | 160 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.33 | 0.65 | 56.4 | 161.2 | 0 | 0/0 | 0 | 2180 | 158 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.27 | 0.83 | 34.5 | 102.9 | 0 | 0/0 | 0 | 2063 | 182 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.28 | 0.92 | 34.1 | 101.0 | 0 | 0/0 | 0 | 2042 | 169 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.85 | 99.00 | 0.61 | 32.7 | 95.7 | 2 | 0/0 | 0 | 2026 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-18 | |
| TestTime | Test Time | 14:11 | |
| TestDuration | Duration | 1:32:41 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 73 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
