Test Date: 2016-01-12 12:57
Analysis date: 2016-05-26 07:44
Analysis date: 2016-05-26 07:44
M2131 XRayHRQualification
Summary
| Module | Module | M2131 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 99.27 | 0.42 | 72.9 | 0 | 24.2 | 0/0 | 0 | 1952 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.03 | 0.61 | 71.0 | 0 | 23.2 | 0/0 | 0 | 1959 | 154 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.32 | 0.51 | 67.1 | 0 | 21.8 | 0/0 | 0 | 1947 | 157 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.36 | 0.59 | 126.2 | 0 | 43.5 | 0/0 | 0 | 2110 | 168 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.32 | 0.83 | 136.3 | 0 | 47.1 | 0/0 | 0 | 2115 | 169 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.38 | 0.61 | 157.3 | 0 | 56.0 | 0/0 | 0 | 2166 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.40 | 0.54 | 137.8 | 0 | 47.7 | 0/0 | 0 | 2119 | 157 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.31 | 2.45 | 164.5 | 0 | 58.3 | 0/0 | 0 | 2200 | 169 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.34 | 0.68 | 155.5 | 0 | 54.0 | 0/0 | 0 | 2161 | 163 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.38 | 0.46 | 139.4 | 0 | 48.3 | 0/0 | 0 | 2138 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.37 | 0.42 | 150.4 | 0 | 52.7 | 0/0 | 0 | 2155 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.37 | 0.72 | 132.8 | 0 | 45.3 | 0/0 | 0 | 2132 | 173 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.34 | 0.5 | 117.8 | 0 | 39.8 | 0/0 | 0 | 2066 | 182 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.33 | 0.48 | 65.8 | 0 | 21.4 | 0/0 | 0 | 1957 | 175 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.88 | 99.32 | 0.5 | 69.4 | 1 | 22.6 | 0/0 | 0 | 1969 | 163 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 99.07 | 0.52 | 62.7 | 0 | 20.6 | 0/0 | 0 | 1935 | 156 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-12 | |
| TestTime | Test Time | 12:57 | |
| TestDuration | Duration | 1:30:41 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
