Test Date: 2016-01-11 13:46
Analysis date: 2016-05-26 07:52
Analysis date: 2016-05-26 07:52
M2133 XRayHRQualification
Summary
| Module | Module | M2133 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 18 | |
| BumpBondingDefects | Bump Bonding Defects | 16 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.28 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.84 | 99.12 | 0.82 | 85.4 | 3 | 29.0 | 0/0 | 0 | 1961 | 147 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.06 | 0.73 | 99.1 | 0 | 33.6 | 0/0 | 0 | 2032 | 167 | 0 |
|
Chip 2
|
A
|
7 | 0 | 99.82 | 99.05 | 0.84 | 85.5 | 6 | 28.4 | 0/0 | 0 | 1934 | 171 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.33 | 0.71 | 145.4 | 0 | 50.2 | 0/0 | 0 | 2143 | 159 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.32 | 0.67 | 155.6 | 0 | 54.1 | 0/0 | 0 | 2154 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.35 | 0.75 | 182.9 | 0 | 64.4 | 0/0 | 0 | 2225 | 159 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.33 | 0.65 | 164.9 | 0 | 57.0 | 0/0 | 0 | 2175 | 160 | 0 |
|
Chip 7
|
A
|
4 | 0 | 99.86 | 99.36 | 0.49 | 162.1 | 4 | 55.6 | 0/0 | 0 | 2170 | 159 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.89 | 99.36 | 0.67 | 181.1 | 1 | 62.4 | 0/0 | 0 | 2218 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.35 | 0.72 | 183.5 | 0 | 63.0 | 0/0 | 0 | 2199 | 172 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.32 | 0.92 | 182.5 | 0 | 63.6 | 0/0 | 0 | 2213 | 166 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.32 | 0.54 | 148.9 | 0 | 51.0 | 0/0 | 0 | 2152 | 162 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.32 | 0.83 | 152.6 | 0 | 52.5 | 0/0 | 0 | 2153 | 169 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.83 | 99.32 | 1.01 | 85.4 | 1 | 28.1 | 0/0 | 0 | 1970 | 168 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.88 | 99.34 | 0.43 | 96.7 | 0 | 32.4 | 0/0 | 0 | 1992 | 173 | 0 |
|
Chip 15
|
A
|
2 | 0 | 99.88 | 99.31 | 0.46 | 92.6 | 1 | 31.6 | 0/0 | 0 | 2009 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-11 | |
| TestTime | Test Time | 13:46 | |
| TestDuration | Duration | 3:28:11 | |
| pXar | pXar version | prod-12+23~g94e35a9 | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
