Test Date: 2016-01-19 10:15
Analysis date: 2016-05-26 08:02
Analysis date: 2016-05-26 08:02
M2134 XRayHRQualification
Summary
| Module | Module | M2134 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.29 | % |
| Noise | Mean Noise | 160 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.85 | 98.98 | 0.62 | 31.6 | 94.4 | 0 | 0/0 | 0 | 2026 | 177 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.27 | 1.18 | 29.6 | 89.9 | 0 | 0/0 | 0 | 2018 | 161 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.33 | 0.45 | 27.9 | 85.3 | 0 | 0/0 | 0 | 2004 | 161 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.24 | 0.59 | 45.0 | 132.0 | 0 | 0/0 | 0 | 2129 | 158 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.35 | 0.73 | 51.7 | 150.7 | 0 | 0/0 | 0 | 2159 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.36 | 0.6 | 62.1 | 176.4 | 0 | 0/0 | 0 | 2222 | 148 | 0 |
|
Chip 6
|
A
|
3 | 0 | 99.87 | 99.34 | 0.6 | 59.9 | 173.4 | 3 | 0/0 | 0 | 2204 | 158 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.38 | 0.61 | 62.0 | 180.1 | 0 | 0/0 | 0 | 2168 | 152 | 1 |
|
Chip 8
|
A
|
1 | 0 | 99.87 | 99.33 | 0.49 | 60.7 | 176.2 | 1 | 0/0 | 0 | 2205 | 161 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.88 | 99.33 | 0.59 | 54.2 | 158.2 | 1 | 0/0 | 0 | 2141 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.85 | 99.36 | 0.66 | 59.7 | 171.3 | 0 | 0/0 | 0 | 2192 | 154 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.32 | 0.74 | 50.6 | 147.8 | 0 | 0/0 | 0 | 2151 | 163 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.34 | 0.71 | 47.3 | 139.4 | 0 | 0/0 | 0 | 2124 | 164 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.38 | 0.51 | 26.3 | 80.1 | 0 | 0/0 | 0 | 2002 | 158 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.83 | 98.98 | 0.68 | 29.9 | 90.5 | 0 | 0/0 | 0 | 2019 | 166 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 99.33 | 1.06 | 27.8 | 83.8 | 0 | 0/0 | 0 | 2008 | 161 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-01-19 | |
| TestTime | Test Time | 10:15 | |
| TestDuration | Duration | 1:25:31 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
