Test Date: 2016-02-08 11:28
Analysis date: 2016-05-26 09:20
Analysis date: 2016-05-26 09:20
M2148 XRayHRQualification
Summary
| Module | Module | M2148 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 36 | |
| BumpBondingDefects | Bump Bonding Defects | 34 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.31 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
14 | 0 | 99.88 | 99.34 | 0.62 | 29.5 | 88.9 | 14 | 0/0 | 0 | 1981 | 176 | 0 |
|
Chip 1
|
A
|
5 | 0 | 99.87 | 99.40 | 0.41 | 30.9 | 93.9 | 5 | 0/0 | 0 | 2033 | 176 | 0 |
|
Chip 2
|
A
|
3 | 0 | 99.86 | 99.15 | 0.46 | 25.5 | 78.8 | 3 | 0/0 | 0 | 1980 | 163 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.87 | 99.37 | 0.87 | 46.6 | 136.8 | 1 | 0/0 | 0 | 2112 | 163 | 0 |
|
Chip 4
|
A
|
10 | 0 | 99.88 | 99.39 | 0.54 | 49.7 | 145.5 | 10 | 0/0 | 0 | 2149 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.35 | 0.79 | 60.5 | 173.8 | 0 | 0/0 | 0 | 2193 | 164 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.36 | 0.55 | 54.8 | 159.6 | 0 | 0/0 | 0 | 2174 | 166 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.32 | 0.82 | 59.1 | 171.8 | 0 | 0/0 | 0 | 2187 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.38 | 0.44 | 53.1 | 156.8 | 0 | 0/0 | 0 | 2133 | 152 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.34 | 0.49 | 58.6 | 170.2 | 0 | 0/0 | 0 | 2185 | 164 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.87 | 99.34 | 0.83 | 61.8 | 177.0 | 0 | 0/0 | 0 | 2153 | 161 | 1 |
|
Chip 11
|
A
|
0 | 0 | 99.90 | 99.34 | 0.62 | 53.1 | 154.4 | 0 | 0/0 | 0 | 2177 | 164 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.35 | 0.64 | 44.5 | 132.2 | 0 | 0/0 | 0 | 2105 | 162 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.86 | 99.22 | 0.61 | 26.7 | 82.1 | 1 | 0/0 | 0 | 1955 | 168 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.03 | 0.54 | 32.4 | 97.8 | 0 | 0/0 | 0 | 2041 | 171 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.88 | 99.29 | 0.48 | 29.0 | 87.6 | 0 | 0/0 | 0 | 1984 | 164 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-08 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 1:35:46 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
