Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:45
Analysis date: 2016-05-26 09:45
M2152 XRayHRQualification
Summary
| Module | Module | M2152 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 62 | |
| BumpBondingDefects | Bump Bonding Defects | 60 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.36 | % |
| Noise | Mean Noise | 172 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
16 | 0 | 99.89 | 99.36 | 0.55 | 33.9 | 99.3 | 16 | 0/0 | 0 | 2037 | 174 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.89 | 99.35 | 0.46 | 33.6 | 100.2 | 1 | 0/0 | 0 | 2029 | 175 | 0 |
|
Chip 2
|
A
|
11 | 0 | 99.88 | 99.38 | 0.4 | 33.0 | 99.4 | 11 | 0/0 | 0 | 2011 | 192 | 0 |
|
Chip 3
|
A
|
2 | 0 | 99.88 | 99.35 | 0.56 | 52.2 | 150.3 | 2 | 0/0 | 0 | 2137 | 164 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.85 | 99.31 | 0.79 | 54.6 | 157.8 | 1 | 0/0 | 0 | 2146 | 166 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.35 | 0.7 | 68.0 | 193.2 | 0 | 0/0 | 0 | 2215 | 169 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.38 | 0.65 | 63.4 | 181.6 | 0 | 0/0 | 0 | 2194 | 171 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.88 | 99.33 | 0.6 | 67.9 | 194.1 | 1 | 0/0 | 0 | 2225 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.38 | 0.49 | 64.0 | 181.1 | 0 | 0/0 | 0 | 2232 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.41 | 0.46 | 70.2 | 198.7 | 0 | 0/0 | 0 | 2265 | 178 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.88 | 99.35 | 0.5 | 66.0 | 184.2 | 0 | 0/0 | 0 | 2163 | 166 | 2 |
|
Chip 11
|
A
|
5 | 0 | 99.88 | 99.36 | 0.65 | 56.1 | 160.1 | 5 | 0/0 | 0 | 2183 | 175 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.89 | 99.43 | 0.58 | 51.6 | 147.6 | 2 | 0/0 | 0 | 2138 | 172 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.84 | 99.32 | 0.91 | 31.1 | 93.2 | 2 | 0/0 | 0 | 2000 | 173 | 0 |
|
Chip 14
|
A
|
7 | 0 | 99.89 | 99.30 | 0.57 | 31.6 | 93.9 | 7 | 0/0 | 0 | 2022 | 177 | 0 |
|
Chip 15
|
A
|
12 | 0 | 99.86 | 99.35 | 0.48 | 33.4 | 96.6 | 12 | 0/0 | 0 | 2041 | 171 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-09 | |
| TestTime | Test Time | 11:35 | |
| TestDuration | Duration | 1:27:30 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
