Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:57
Analysis date: 2016-05-26 09:57
M2154 XRayHRQualification
Summary
| Module | Module | M2154 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 114 | |
| BumpBondingDefects | Bump Bonding Defects | 112 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.27 | % |
| Noise | Mean Noise | 180 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
15 | 0 | 99.84 | 99.02 | 0.59 | 23.9 | 72.1 | 15 | 0/0 | 0 | 1966 | 183 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.03 | 0.59 | 25.6 | 78.1 | 0 | 0/0 | 0 | 1958 | 190 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.87 | 99.32 | 0.32 | 22.5 | 68.7 | 0 | 0/0 | 0 | 1953 | 180 | 0 |
|
Chip 3
|
A
|
3 | 0 | 99.89 | 99.37 | 0.49 | 38.3 | 112.5 | 3 | 0/0 | 0 | 2078 | 175 | 0 |
|
Chip 4
|
A
|
6 | 0 | 99.87 | 99.27 | 0.53 | 40.6 | 119.4 | 6 | 0/0 | 0 | 2087 | 174 | 0 |
|
Chip 5
|
A
|
5 | 0 | 99.88 | 99.30 | 0.58 | 52.7 | 152.9 | 5 | 0/0 | 0 | 2151 | 171 | 0 |
|
Chip 6
|
A
|
6 | 0 | 99.88 | 99.38 | 0.52 | 44.6 | 130.9 | 6 | 0/0 | 0 | 2102 | 170 | 0 |
|
Chip 7
|
A
|
24 | 0 | 99.87 | 99.32 | 0.61 | 47.3 | 138.5 | 24 | 0/0 | 0 | 2113 | 175 | 0 |
|
Chip 8
|
A
|
36 | 0 | 99.87 | 99.30 | 1.13 | 52.9 | 154.3 | 35 | 0/0 | 0 | 2130 | 184 | 1 |
|
Chip 9
|
A
|
3 | 0 | 99.86 | 99.33 | 1.46 | 55.3 | 160.8 | 2 | 0/0 | 0 | 2141 | 190 | 1 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.38 | 0.49 | 55.5 | 158.7 | 0 | 0/0 | 0 | 2156 | 175 | 0 |
|
Chip 11
|
A
|
2 | 0 | 99.88 | 99.32 | 0.77 | 49.1 | 144.1 | 2 | 0/0 | 0 | 2131 | 185 | 0 |
|
Chip 12
|
A
|
6 | 0 | 99.88 | 99.35 | 0.49 | 42.1 | 123.3 | 6 | 0/0 | 0 | 2054 | 183 | 0 |
|
Chip 13
|
A
|
2 | 0 | 99.86 | 99.22 | 0.46 | 24.7 | 74.9 | 2 | 0/0 | 0 | 1970 | 178 | 0 |
|
Chip 14
|
A
|
3 | 0 | 99.87 | 99.30 | 0.54 | 27.4 | 82.5 | 3 | 0/0 | 0 | 1996 | 182 | 0 |
|
Chip 15
|
A
|
3 | 0 | 99.87 | 99.13 | 0.47 | 26.7 | 79.6 | 3 | 0/0 | 0 | 1932 | 180 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-09 | |
| TestTime | Test Time | 11:35 | |
| TestDuration | Duration | 1:27:30 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
