Test Date: 2016-02-11 16:37
Analysis date: 2016-05-26 10:21
Analysis date: 2016-05-26 10:21
M2158 XRayHRQualification
Summary
| Module | Module | M2158 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 7 | |
| BumpBondingDefects | Bump Bonding Defects | 2 | |
| NoisyPixels | Noisy Pixels | 5 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.30 | 0.44 | 81.9 | 0 | 27.3 | 0/0 | 0 | 1973 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.15 | 0.55 | 90.6 | 0 | 30.3 | 0/0 | 0 | 1997 | 170 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.82 | 99.02 | 0.78 | 79.3 | 0 | 26.0 | 0/0 | 0 | 1930 | 166 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.32 | 0.61 | 145.1 | 0 | 50.4 | 0/0 | 0 | 2121 | 170 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.27 | 1.13 | 144.9 | 0 | 49.8 | 0/0 | 0 | 2121 | 167 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.36 | 0.69 | 179.8 | 0 | 63.9 | 0/0 | 0 | 2234 | 171 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.37 | 0.73 | 181.1 | 0 | 63.4 | 0/0 | 0 | 2214 | 168 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.37 | 0.48 | 178.5 | 0 | 62.4 | 0/0 | 0 | 2199 | 166 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.31 | 0.58 | 187.1 | 0 | 65.7 | 0/0 | 0 | 2198 | 160 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.35 | 0.5 | 180.0 | 0 | 63.1 | 0/0 | 0 | 2207 | 164 | 0 |
|
Chip 10
|
A
|
3 | 0 | 99.87 | 99.38 | 0.73 | 187.0 | 0 | 66.8 | 0/0 | 0 | 2127 | 165 | 3 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.29 | 0.7 | 155.1 | 0 | 54.0 | 0/0 | 0 | 2150 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.34 | 0.55 | 134.2 | 0 | 45.8 | 0/0 | 0 | 2086 | 164 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.87 | 99.30 | 0.41 | 83.8 | 2 | 27.6 | 0/0 | 0 | 1966 | 164 | 1 |
|
Chip 14
|
A
|
0 | 0 | 99.89 | 99.32 | 0.64 | 88.6 | 0 | 29.4 | 0/0 | 0 | 2002 | 164 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.33 | 0.75 | 95.2 | 0 | 32.5 | 0/0 | 0 | 1998 | 179 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-11 | |
| TestTime | Test Time | 16:37 | |
| TestDuration | Duration | 1:27:53 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 68 | |
| nWarnings | # Warnings | 11 | |
| channel_0_count | Channel 0 | 5 | |
| channel_1_count | Channel 1 | 5 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 1 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_readback_count | Readback start marker | 8 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
