Test Date: 2016-02-24 09:58
Analysis date: 2016-05-26 10:34
Analysis date: 2016-05-26 10:34
M2161 XRayHRQualification
Summary
| Module | Module | M2161 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 0 | 99.85 | 99.01 | 0.6 | 24.6 | 72.6 | 4 | 0/0 | 0 | 1950 | 162 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.85 | 99.04 | 0.63 | 25.4 | 76.0 | 2 | 0/0 | 0 | 1968 | 161 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.88 | 99.23 | 0.38 | 19.7 | 61.1 | 0 | 0/0 | 0 | 1915 | 149 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.34 | 0.68 | 44.9 | 130.0 | 0 | 0/0 | 0 | 2102 | 172 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.90 | 99.36 | 0.47 | 45.5 | 132.3 | 0 | 0/0 | 0 | 2101 | 167 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.39 | 0.44 | 46.4 | 134.1 | 0 | 0/0 | 0 | 2103 | 163 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.34 | 0.48 | 47.5 | 137.5 | 0 | 0/0 | 0 | 2106 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.35 | 0.67 | 48.8 | 141.5 | 0 | 0/0 | 0 | 2115 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.88 | 99.37 | 0.47 | 43.3 | 127.4 | 0 | 0/0 | 0 | 2085 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.05 | 0.64 | 38.8 | 114.2 | 0 | 0/0 | 0 | 2052 | 159 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.40 | 0.3 | 44.3 | 128.7 | 0 | 0/0 | 0 | 2101 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.36 | 0.33 | 36.9 | 108.5 | 0 | 0/0 | 0 | 2050 | 160 | 0 |
|
Chip 12
|
A
|
2 | 0 | 99.86 | 99.06 | 0.69 | 32.7 | 97.1 | 2 | 0/0 | 0 | 2017 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.10 | 0.32 | 18.1 | 55.5 | 0 | 0/0 | 0 | 1930 | 156 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.07 | 0.41 | 20.2 | 61.4 | 0 | 0/0 | 0 | 1952 | 160 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.88 | 99.38 | 0.27 | 21.3 | 63.4 | 0 | 0/0 | 0 | 1922 | 163 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-24 | |
| TestTime | Test Time | 09:58 | |
| TestDuration | Duration | 1:26:39 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
