Test Date: 2016-02-24 09:58
Analysis date: 2016-05-26 10:46
Analysis date: 2016-05-26 10:46
M2163 XRayHRQualification
Summary
| Module | Module | M2163 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.34 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.87 | 99.32 | 0.51 | 31.9 | 92.4 | 0 | 0/0 | 0 | 2033 | 169 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.89 | 99.33 | 0.31 | 30.7 | 91.2 | 0 | 0/0 | 0 | 2013 | 164 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.86 | 99.36 | 0.62 | 29.1 | 87.3 | 1 | 0/0 | 0 | 2017 | 172 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.37 | 0.4 | 54.5 | 153.9 | 0 | 0/0 | 0 | 2165 | 173 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.88 | 99.33 | 0.78 | 55.2 | 157.0 | 0 | 0/0 | 0 | 2167 | 168 | 2 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.34 | 0.6 | 57.9 | 165.9 | 0 | 0/0 | 0 | 2188 | 158 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.91 | 99.36 | 0.72 | 61.7 | 174.7 | 0 | 0/0 | 0 | 2203 | 160 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.89 | 99.40 | 0.5 | 65.2 | 182.8 | 2 | 0/0 | 0 | 2251 | 161 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.36 | 0.5 | 56.4 | 162.9 | 0 | 0/0 | 0 | 2179 | 161 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.90 | 99.36 | 0.73 | 54.8 | 158.4 | 0 | 0/0 | 0 | 2175 | 157 | 0 |
|
Chip 10
|
A
|
2 | 0 | 99.88 | 99.34 | 1.56 | 59.1 | 168.6 | 0 | 0/0 | 0 | 2145 | 155 | 1 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.35 | 0.59 | 51.3 | 146.8 | 0 | 0/0 | 0 | 2154 | 161 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.88 | 99.36 | 0.42 | 52.8 | 150.4 | 0 | 0/0 | 0 | 2156 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.87 | 99.31 | 0.67 | 29.9 | 89.4 | 0 | 0/0 | 0 | 1999 | 175 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.28 | 0.71 | 34.3 | 100.5 | 0 | 0/0 | 0 | 2038 | 176 | 0 |
|
Chip 15
|
A
|
1 | 0 | 99.86 | 99.25 | 0.57 | 33.0 | 95.4 | 1 | 0/0 | 0 | 2036 | 176 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-24 | |
| TestTime | Test Time | 09:58 | |
| TestDuration | Duration | 1:26:39 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
